P. 51

试验研究




   DOI : 10.11973 / ws j c202306004

           微焦点            DR      成像技术在索类火工品制造


                                     检测中的应用




                              张海东, 王启然, 周涵彬, 赵 为, 赵永杰, 魏 娜

                                 ( 陕西应用物理化学研究所, 西安 710061 )
           摘 要: 开展了带状、 盘状等多类型索类火工品工件内部缺陷的 X 射线实时成像检测。针对

       带状样品, 通过带状样品移动台齿轮机构的传输, 实现对样品位移的高精度控制, 最终实现了样品
       的多角度检测, 解决了大直径柔性导爆索的内部结构、 装药密度以及缺陷的检测; 针对盘状样品, 通
       过盘状样品旋转台的高精度偏转机构, 实现了样品的±45° 偏转, 解决了小直径柔性导爆索样品多角
       度的内部结构、 装药密度以及缺陷的检测, 有望为索类火工品制造过程的 DR检测提供一些参考。

           关键词: 微焦点 DR 成像; 索类火工品; 缺陷

         中图分类号: TG115.28   文献标志码: A   文章编号: 1000-6656 ( 2023 ) 06-0017-04

          A pp licationofmicrofocusDRima g in g technolo gy inmanufacturin g ins p ectionof

                                       cablet yp e py rotechnics


                   ZHANGHaidon g WANGQ iran , ZHOUHanbin , ZHAO Wei , ZHAOYon gj ie , WEINa
                                ,

                      ( ShaanxiInstituteofA pp liedPh y sicsandChemistr y , Xi ’ an710061 , China )

           Abstract : B y conductin gX-ra yreal-timeima g in g testin goncablet yp epy rotechnics , nondestructivetestin gof

       internaldefectsinmulti p let yp esofwork p iecessuchasrods , cables , anddiscswassolved.Fortheribbonsam p le ,

       hi g h- p recisioncontrolofsam p ledis p lacementwasachievedthrou g hthe g earmechanismtransmissionoftheribbon

       sam p lemovin gp latform.Theribbonsam p lemovin gp latformcandeflectwithin±45°alon g theX-axis , achievin g

       multian g ledetectionofthesam p lesandsolvin g theinternalstructure , char g edensit y , anddefectdetectionoflar g e-

       diameterflexibledetonatin gcords.Fordiscsha p edsam p les , ahi g h- p recisiondeflection mechanism ofthedisc

       sha p edsam p lerotationtablewasusedtoachieve±45°deflectionofthesam p le , solvin g the p roblemofmultian g le

       internalstructure , char g edensit y , anddefectdetectionofsmall-diameterflexibledetonatin gcordsam p les.It

       wasex p ectedto p rovidesomereferenceforDRdetectioninthemanufacturin gp rocessofcablet yp e py rotechnics.

           Ke ywords : microfocalDRima g in g ; cablet yp e py rotechnic ; defect
     索类火工品主要包括导火索、 导爆索和切割索,                          的金属管内填装炸药, 经过冷拔、 软化、 编织等工艺制
   其中导爆索主要用于传递爆轰信号, 外形和结构都与                          成的。

   导火索的相似。导爆索常以金属( 铅、 铜、 银) 做外皮,                          为解决索类火工品内部质量一致性差、 内部装

                                               -1    药密度不均匀的问题, 需要对其质量进行检测。传
   药芯常用黑索金、 太安等烈性炸药, 以7000m · s
   或者更高的速度传爆。文章主要的研究对象为金属                            统射线照相无损检测技术存在内部缺陷图像质量差
   柔性导爆索, 金属柔性导爆索是在铅、 银等金属制成                         且无法放大图像、 无法识别质量缺陷的技术缺点。
                                                     同时, 检测大长径比索类火工品时存在弯曲半径大、
                                                     检测空间受限、 效率低等技术难点, 开展了索类火工
      收稿日期: 2022-09-22
                                                     品高分辨率微焦点 DR ( 数字射线) 无损检测技术应
      作者简介: 张海东( 1983- ), 男, 硕士, 工程师, 主要从事军品火
   工品的 X 射线无损检测工作                                    用研究, 同时研究了带状、 盘状等类型工件的无损检
      通信作者: 张海东, 286653441@ qq .com                  测, 实现了索类火工品样品的多角度无损检测。
                                                                                                7
                                                                                               1
                                                                             2023年 第45卷 第6期
                                                                                     无损检测
