无损检测新技术发展与应用专题




   DOI : 10.11973 / ws j c202210005

           空间数据扫描技术在大型常压储罐变形


                                     检测中的应用




                           邢   述 , 杜邦胜 , 都   亮 , 王   十 , 杜家超 , 郭   洪      1
                                         2
                                 1
                                                  1
                                                          1
                                                                  1

         ( 1. 中国特种设备检测研究院, 北京 100029 ; 2. 中国石油大连石化石油储运公司, 大连 116610 )

           摘   要:储罐在服役过程中受基础沉降、 工艺操作不当、 外部载荷变化等因素影响, 罐体易发
       生变形或倾斜。常规检测手段( 铅锤检测、 全站仪扫描、 水准仪测量等) 的检测精度易受到现场环境
       和人员水平的限制, 后期数据处理工作量大。为解决上述问题, 采用三维激光扫描仪对储罐整体或
       局部进行空间数据扫描, 获取点云数据, 通过拼接、 降噪、 滤波、 网格化处理, 获取储罐的数字模型,
       可实现对储罐变形、 圆度、 垂直度、 沉降的分析与评价。与常规手段相比, 空间数据扫描技术工作效
       率高、 检测范围广、 测量精度高、 数据保存与处理更为便捷。

           关键词:常压储罐; 空间数据扫描; 网格模型; 局部变形; 刚性倾斜

          中图分类号: TG115.28    文献标志码: A    文章编号: 1000-6656 ( 2022 ) 10-0020-05

                 A pp licationofs p atialdatascannin g technolo gy inlar g eatmos p heric

                                 stora g etankdeformationdetection


                                         ,
                           1
                                        2
                                                                       1
                                                            1
                    XINGShu , DUBan g shen g DULian g 1 , WANGShi , DUJiachao , GUOHon g 1




                  ( 1ChinaS p ecialE q ui p mentIns p ectionandResearchInstitute , Bei j in g100029 , China ;

















             2.DalianPetrochemicalOilStora g e& Trans p ortationCom p an yofCNPC , Dalian116610 , China )

















           Abstract : Durin g theserviceofthetank , itwillbedeformedortiltedduetothesettlementofthefoundation ,



       im p ro p erp rocesso p eration , andchan g esin externalloads.Thedetection accurac y ofconventionaldetection

       methods ( leadhammerdetection , wholestationscannin g , levelmeasurement , etc. ) iseasil y limitedb y theon-site

       environmentandp ersonnellevel , andthelaterdatap rocessin g workloadislar g e.Inordertosolvetheabove

       p roblems , athree-dimensionallaserscannerisusedtoscanthes p atialdataofthetankinwholeorinp art , andthe

       p ointclouddataisobtained.Throu g hs p licin g , noisereduction , filterin gandg ridp rocessin g , thedi g italmodelof

       thetankcanbeobtained , whichcanrealizetheanal y sisandevaluationoftankdeformation , roundness , verticalit y

       andsettlement.Com p aredwithconventionalmeans , hi g hefficienc y , widedetectionran g e , the p resentoneisshown

       tobeofhi g hmeasurementaccurac y , andmoreconvenientdatastora g eandp rocessin g .

           Ke ywords : atmos p hericstora g etank ; s p atialdatascannin g ; g ridmodel ; localdeformation ; ri g idtilt
      大型常压储罐是企业间大宗能源贸易结算的主                           基础沉降、 工艺操作不当、 外部载荷变化等因素影
   要储存设备, 在商业、 军事、 民用、 交通、 航空、 石化行                   响, 罐体易发生变形或倾斜。当罐体变形累积到一
   业中有着非常广泛的应用。在储罐服役过程中, 受                           定程度后, 可能引发卡盘、 浮顶偏沉、 漏液、 着火等事
                                                     故  [ 1 ] , 给储罐安全运行带来重大威胁。常规的罐体
                                                     倾斜、 变形检测方法( 如铅锤检测) 操作简单, 但易受
      收稿日期: 2022-04-18
                                                     到天气环境等外部因素影响; 采用全站仪获取罐壁
      作者简介: 邢   述( 1989- ), 男, 本科, 工程师, 主要从事常压储
   罐检验检测、 风险评估、 完整性评价、 合于使用评价等专业方向的研                 上的离散点坐标分析变形情况, 其工作量大、 效率
   究工作                                               低、 自动化程度低       [ 2 ] 。文章给出一种基于空间数据
                                                     扫描技术的储罐变形检测方法, 该方法自动化程度
      通信作者: 王   十, wan g shi@csei.or g .cn
