试验研究
试验研究

DOI：10.11973/wsjc202408004

钢丝绳芯传送带损伤的漏磁检测

杨志军，张博文，蒙昌彭，赵亚忠
（东北石油大学 机械科学与工程学院，大庆 163318）

摘 要：钢丝绳芯传送带是用于输送物料的高强度传送带，广泛应用于采矿、建筑、冶金等领
域，其在长时间运行后，内部钢丝绳会出现断丝、磨损等缺陷，影响生产安全。基于漏磁检测技术
开展了钢丝绳芯传送带的损伤检测，首先建立了含有不同类型和不同截面积损伤的传送带漏磁检
测有限元模型，分析了缺陷漏磁场空间分布特性和变化规律，然后在实验室条件下开展传送带漏磁
检测试验，采用滑动平均降噪与小波降噪相结合的方法对检测信号进行降噪处理，降噪后的信号能
够清晰地显示出缺陷损伤严重程度。仿真和试验结果表明，漏磁检测技术能够检测出钢丝绳芯传
送带中不同类型和不同截面积的损伤，能够为传送带使用和维护提供决策依据。
关键词：钢丝绳芯传送带；漏磁检测；有限元分析；滑动平均；小波降噪

中图分类号：TG115.28 文献标志码：A 文章编号：1000-6656(2024)08-0018-06

Magnetic leakage detection for damage of wire rope core conveyor belts

YANG Zhijun, ZHANG Bowen, MENG Changpeng, ZHAO Yazhong
（College of Mechanical Science and Engineering, Northeast Ptroleume University, Daqing 163318, China）
Abstract: Steel wire rope core conveyor belt is a high-strength conveyor belt used for conveying materials,
widely used in mining, construction, metallurgy and other fields. However, after long-term operation of the steel wire
core conveyor belt, the internal steel wire rope may have defects such as breakage and wear, leading to equipment
damage during production and affecting production safety. In this paper, based on magnetic flux leakage detection
technology, damage detection of steel wire rope core conveyor belts was carried out. Firstly, a finite element model
for magnetic flux leakage detection of steel wire rope core conveyor belts with different types and cross-sectional
areas of damage was established, and the spatial distribution characteristics and variation rules of defect magnetic
flux leakage were analyzed. Then, magnetic flux leakage detection experiments of steel wire rope core conveyor belts
were carried out under laboratory conditions, and a combination of sliding average denoising and wavelet denoising
was used for signal denoising processing. The denoised signal can clearly display the severity of defect damage.
Simulation and experimental results showed that magnetic flux leakage detection technology can detect different types
and cross-sectional areas of damages in steel wire rope core conveyor belts, providing decision-making basis for the
use, maintenance, and safe operation of steel wire rope core conveyor belts.
Key words: steel cord core conveyor belt; magnetic leakage detection; finite element analysis; sliding average; wavelet
denoising

钢丝绳芯传送带是一种被橡胶包覆，内部分布 着多根等距排列的钢丝绳的传输工具。因其拥有大
功率、远距离、大倾角、大运量、高效率、连续运转和
收稿日期：2024-01-16 使用寿命长等优点，被广泛应用于需要长距离、大载
基金项目：国家市场监督管理总局科技计划项目（2022MK162）；
荷运输的领域 。但由于传送带通常在高强度、大
[1]
浙江省市场监督管理局科技计划项目（20200119）
负荷的恶劣环境下服役，传送带内部钢丝绳承受着
作者简介：杨志军（1976—），男，博士，副教授，主要从事现代无
损检测研究以及相关仪器开发等科研工作 滚压、弯折、拉伸、冲击等巨大应力变化，同时受周
通信作者：张博文，bwz1002@163.com 围环境的长期影响，容易产生断丝、断股、磨损等缺
18
