试验研究




   DOI : 10.11973 / ws j c202311003

               拉挤梁风电叶片的相控阵超声检测


                                          数据分析




                               李得彬 , 卢同红 , 佟明冬 , 王先锋 , 高 阳            2
                                             2
                                                      1
                                                              1
                                     1

        ( 1. 上海麒济检测科技有限公司, 上海 200540 ; 2. 中材科技风电叶片股份有限公司, 北京102101 )
           摘 要: 针对拉挤梁风电叶片相控阵超声检测时, 信号受叶片特殊结构及材料各向异性影响

       出现数据信噪比低、 缺陷识别困难的问题, 通过分析叶片结构及其典型缺陷, 明确相控阵超声图像
       信号与叶片结构的对应关系, 并提出了高效、 准确的数据分析流程。试验结果表明, 该方法有助于
       提高风电行业数据分析工作的质量。
           关键词: 风电叶片; 拉挤梁; 超声相控阵; 数据分析


         中图分类号: TG115.28   文献标志码: A   文章编号: 1000-6656 ( 2023 ) 11-0010-04


     Anal y sisof p hasedarra y ultrasonictestin g datafor p ultrusionbeamofwindturbineblades


                                                       1
                                                                      1
                                        2
                            1
                     LIDebin , LUTon g hon g TONGMin g don g WANGXianfen g GAOYan g 2
                                                                       ,
                                         ,
                                                        ,

                     ( 1.Shan g haiQIJIIns p ectionTechnolo gyCo. , Ltd. , Shan g hai200540 , China ;

                          2.SinomaWindPowerBladeCo. , Ltd. , Bei j in g 102101 , China )

           Abstract : Durin g the p hasedarra y ultrasonictestin g ofwindturbinebladeswithp ultrusionbeam , thesi g nalis

       affectedb y thes p ecialstructureofthebladeandtheanisotro pyofitsmaterial , resultin g inthelowsi g nal-to-noise

       ratioofthedata , andthedefectidentificationisdifficultinthedataanal y sis.Tosolvethisp roblem , thisp a p er

       anal y zesthestructureandt yp icaldefectsofwindturbinebladeswithp ultrusionbeam , clarifiesthecorres p ondin g

       relationshi pbetweenp hasedarra yultrasonicima g esi g nalandthestructureofwindturbinebladeswithp ultrusion

       beam , andp ro p osesanefficientandaccurateanal y sis p rocess.Afterverification , thismethodhel p stoim p rovethe

       q ualit y ofdataanal y sisworkinthewindp owerindustr y .

           Ke ywords : windturbineblade ; p ultrusionbeam ; p hasedarra y ultrasonic ; dataanal y sis
     随着我国电力需求的不断增长, 风力发电机组                           测, 及时发现缺陷并采取措施, 是保证风电机组安
   装机容量大型化已是必然趋势。作为承受风力载荷                            全、 稳定运行的重要环节          [ 1 , 2 ] 。
   的重要部件, 风电叶片大型化、 轻量化、 高强度也是                             文章针对拉挤梁风电叶片相控阵超声检测数据
   未来的发展方向。因此拉挤梁结构的风电叶片将是                            开展研究, 通过分析叶片结构及其典型缺陷, 明确相
   未来主要的叶片结构形式之一。在制造过程中, 受                           控阵超声图像信号与叶片结构的对应关系, 并提出
   生产工艺或人员操作等因素影响, 叶片常会出现影                           了高效、 准确的数据分析流程。
   响其结构强度的缺陷, 给风电机组的安全平稳运行                           1 风电叶片结构
   埋下了隐患, 因此在叶片制造阶段对其进行有效检
                                                       进行拉挤梁风电叶片相控阵检测之前, 需要研
                                                     究叶片的结构、 材料和制造工艺, 制定合适的检测
      收稿日期: 2023-03-16
                                                     工艺。
      作者简介: 李得彬( 1984- ), 男, 主要从事电力行为( 含风电叶
                                                          风电叶片是由复合材料制成的薄壳结构, 如图
   片) 超声及相控阵检测工艺开发及涡流交流电磁场检测技术的研究
   工作                                                1所示。其一般由蒙皮、 主梁、 芯材和腹板等部分组
                                                     成, 各部分通过环氧树脂灌注或结构胶黏接的方式
      通信作者: 佟明冬( 1989- ), 男, minton _ ton g @163.com
