试验研究
试验研究

DOI：10.11973/wsjc240124

基于压电导波的复合材料帽型加筋壁板损伤监测

王霞光 ，刘国强 ，王 莉 ，任一鹏 ，黎 玮 ，安雨晴 1,2
1,2
1,2
1,2
1,2
1,2
（1. 中国飞机强度研究所，西安 710065；2. 强度与结构完整性全国重点实验室，西安 710065）
摘 要：通过分析复合材料帽型加筋壁板的损伤特点，将压电导波监测技术引入帽型加筋壁板
的损伤监测中。首先，对导波在帽型加筋结构中的传播机理进行了有限元仿真，结果显示，导波在
帽型加筋中的传播会随着结构形式，呈现先分离后汇合的复杂特点。然后，引入以能量和相关性为
衡量标准的两种损伤指数算法对导波信号进行量化。最后，将压电导波技术结合两种损伤指数算法
应用到复合材料帽型加筋壁板的疲劳试验中。试验结果显示，分层损伤扩展会导致导波信号出现明
显的变化，通过两种损伤指数算法可以识别出帽型加筋上的分层损伤扩展。尽管帽型加筋会增加导
波传播的复杂性，压电导波监测技术对复合材料帽型加筋壁板的筋条损伤监测仍然是有效的。
关键词：复合材料；帽型加筋；压电导波；损伤指数；结构健康监测

中图分类号：TG115.28 文献标志码：A 文章编号：1000-6656(2025)01-0027-06

Damage monitoring of hat-stiffened composite panel based on piezoelectric-based waves

WANG Xiaguang , LIU Guoqiang , WANG Li , REN Yipeng , LI Wei , AN Yuqing 1,2
1,2
1,2
1,2
1,2
1,2
（1. Aircraft Strength Research Institute of China，Xi′an 710065，China;
2. National Key Laboratory of Strength and Structure Integrity，Xi′an 710065，China）
Abstract: By analyzing the damage characteristics of composite hat-stiffened panels, piezoelectric-based guided wave
monitoring technology was introduced into the damage monitoring of hat-stiffened panels. Finite element simulation was
firstly conducted on the propagation mechanism of guided waves in hat shaped reinforcement structure. The simulation
results showed that the propagation of guided waves in the hat-shaped reinforcement exhibited a complex characteristic of
first separation and then convergence with the structural form. In order to quantify guided wave signals, two damage index
algorithms with energy and correlation as measurement criteria were proposed. Finally, the piezoelectric-based guided
wave technology with two damage index algorithms was applied to the fatigue testing of composite hat-stiffened panels.
Experimental results showed that the propagation of lamination damage could cause significant signal changes of guided
waves. The energy damage index and correlation damage index algorithms could identify the propagation of lamination
damage on the hat-stiffened reinforcement. Although hat-stiffened reinforcement increased the complexity of guided wave
propagation, piezoelectric-based guided wave technology was still effective for monitoring the damage of reinforcement
bars in composite hat-stiffened panels.
Key words: composite material; hat-stiffened rib; piezoelectric-based guided wave; damage index; structural health
monitoring

复合材料加筋结构因其构型简单，易于加工成 结构极大增强了复合材料壁板的强度和刚度，使得
型，力学性能优异而备受关注，在航空航天、压力容 结构的整体承载水平大幅提升。在实际工程应用中，
器和轨道交通等领域有着较为广泛的应用 [1-2] 。加筋 载荷、温度、振动等环境因素交替作用可能会对加筋
[3]
区域造成多种损伤，如脱黏、分层及纤维断裂等 。
收稿日期：2024-03-25
筋条的损伤会降低结构的局部强度，严重影响复合
作者简介：王霞光（1987—），男，工程师，硕士，主要从事结构健
康监测专业相关工作 材料壁板的运行安全。因此采用结构健康监测技术
及时获取结构的损伤状态参数信息，对结构的安全
通信作者：王霞光，464275620@qq.com
