基于电磁法的切应变检测系统的设计

基金项目:

山东省教育厅科技计划资助项目(J02A06)

详细信息

Design of Shear Strain Testing System Based on Electromagnetic Testing

摘要: 在机械构件的应变检测中，传统的应变片法由于需接触检测而难以满足检测要求。基于电磁检测原理提出了受扭构件切应变的非接触实时在线定量检测方法，设计了以AT89C52为核心的旋转构件切应变检测系统。介绍该系统的功能、硬件构成、软件设计及其实现。仿真试验表明，该系统运行可靠，检测准确，具有推广应用价值。
- 电磁检测系统 /
- 霍尔元件 /
- 切应变 /
- 硬件 /
- 软件
Abstract: Conventional strain-gauge method can not satisfy the measurement of the strain of mechanical component for its contacting pattern. Non-contact real-time on-line quantitative testing of the shear strain of the component twisted based on electromagnetic testing was put forward. AT89C52 based and angular strain testing system was designed. The system function, hardware structure and software design were also given. Simulation experiment showed that the system could provide reliable and accurate testing and was valuable for practical application.
- Electromagnetic testing system /
- Hall sensor /
- Shear strain /
- Hardware /
- Software

[1]	谭继文，王广丰，舒杰，等.机械构件线应变在线检测新技术研究\[J\].机械科学与技术,2004,23(5):534-535.
[2]	童诗白，华成英.模拟电子技术基础\[M\].北京：高等教育出版社，2001.
[3]	梁廷贵，王裕琛.集成运算放大器电压比较器分册\[M\].北京：科学技术文献出版社,2003.
[4]	高锋.单片微型计算机原理与接口技术\[M\].北京：科学出版社,2003.
