Development of Portable Multifunctional Eddy Current Meter
-
摘要: 介绍了集涡流探伤、电导率测量和涂层测厚功能于一体的便携式多功能涡流仪的实现原理。利用ANSYS软件进行数值模拟，得出涡流检测线圈阻抗的变化规律。提出用相位分析法来抑制提离效应，并在此基础上，设计研制了基于AT91RM9200处理器的多功能涡流仪的测量系统。实验结果表明，该系统具有很好的推广应用前景。Abstract: The basic development principle of portable multifunctional eddy current meter was introduced, which included eddy current testing, measurement for the conductivity of metal material and thickness of cladding. Through numerical simulation in ANSYS software, the changing law of the impedance of probe coil was found, a method that using phase analytical method to correct lift-off effect in the impedance plane was put forward. Based on the principle, the meter system using high performance microprocessor AT91RM9200 was designed. It has a great application prospect.
-
Keywords:
- Eddy current testing /
- Probe-coil /
- Conductivity /
- Lift-off effect /
- Impedance
-
-
[1] 任吉林.电磁无损检测[M].北京：航空工业出版社,1988. [2] 龚曙光，谢桂兰.ANSYS操作命令与参数化编程[M].机械工业出版社,2004. [3] 李龙奎，苏俊宏.基于ANSYS的二维谐性磁场分析[J].应用光学,2005,26(6):38-40. [4] 田 泽.嵌入式系统开发与应用教程[M].北京：北京航空航天大学出版社,2005. [5] 玉 波，朱自强，郭 军.Linux C编程[M].北京：清华大学出版社,2005.
