Radioscopy Applying to Thin-wall Laser Jointing Rings
-
摘要: 利用射线照相的替代技术——X射线实时成像检测技术，对某薄壁圆环的焊缝进行了实时成像检测，结果表明该技术可以检测出试环焊缝中最小为0.4 mm的孔型缺陷，像质计测定的检测灵敏度优于2%。Abstract: As a new technology substitution of film radiography, radioscopy is used to test the welding of jointing ring. The result shows that the hole style defect with 0.4 mm can be detected and its image quality indicator sensitivity is lower than 2%.
-
Keywords:
- Radiographic testing /
- Radioscopy /
- Welding /
- Sensitivity
-
-
[1] 郑世才，刘建春，吴东流，等.射线实时成像检验技术\[J\].无损检测,1996,18(7-12):202. [2] 郑世才.射线实时成象检验技术\[J\].无损检测,2000,22(7):328-333,336. [3] GB 17925—1999，气瓶对接焊缝X射线实时成像检测\[S\]. [4] 曾祥照.气瓶对接焊缝X射线实时成像检测标准概述\[J\].无损检测,2000,22(9):419-422. [5] 曾祥照，张忠诚，张正荣. X射线数字化实时成像技术在天然气管道焊缝探伤中应用的可行性\[J\].无损检测,2001,23(12):530-534. [6] 曾祥照，简志良. X射线实时成像在液化气钢瓶焊缝探伤中的应用\[J\].无损检测,1999,21(2):61-64. [7] 唐鹏林.计算机实时成像在钢瓶探伤中的应用\[J\].无损检测,1999,21(4):182-183. [8] 王世勋.制定直管对接焊缝射线实时成像检验标准时应考虑的几个技术问题\[J\].无损检测,1998,20(9):261-262.
