Effect of 300kV XRays on Gas Components Dissolution in Transformer Oil
-
摘要: 为了将X射线直接数字成像技术引入到变压器的无损检测中,需要确定X射线对变压器油中溶解气体的组分有无影响。利用便携式高频X射线机对带电压的变压器油进行定能量和定时间的照射试验,结果表明,300kV管电压X射线的辐射对变压器油中的溶解气体组分没有影响。该结果可为X射线数字成像透视检测系统对电力充油设备进行可视化检测给予明确、充分的证据,同时为基于X射线的电力设备数字成像系统的应用范围提供了技术支持。Abstract: In order to apply the Xray direct digital imaging technology to the field of nondestructive testing of the transformer, it is necessary to determine whether there exists impact of Xray irradiating on the insulating oil. This paper proposed a research of using Xray to irradiate the transformer oil. The concrete content of the study is to irradiate the applied voltage for given energy and given time by portable high frequency Xray generator. Experimental results show that Xray has little effect on the gas component of transformer oil. This study will provide clear and adequate basis for applying the Xray direct digital imaging technology to the field of nondestructive testing of oil filled electric equipment and it will offer technical support for application of electrical equipment based on digital Xray imaging system as well.
-
Keywords:
- Xray digital imaging technology /
- High energy /
- Oil change /
- Oil chromatogram
-
-
[1] 闫斌,何喜梅,吴童生,等.GIS设备X射线可视化检测技术[J].中国电力,2010,43(7):44-47. [2] 吴章勤,魏杰,况华.GIS的X射线数字成像检测[J].无损检测,2013,35(1):11-15. [3] 王达达,魏杰,于虹.2011年云南电力技术论坛论文集[C]∥云南:[出版者不详],2011. [4] 闫斌,何喜梅,王志惠,等.X射线数字成像检测系统在GIS设备中的应用[J].高压电器,2010(11):89-91. [5] 郭涛涛,王达达,于虹.曝光量在GIS设备X射线可视化无损检测中的选择应用[J].核电子学与探测技术2012,32(5):573-577. [6] 郭涛涛,王达达,高阔.X射线对变压器油的影响研究[J].核电子学与探测技术,2012,32(12):1437-1440. [7] 李衍.承压设备焊缝CR和DR技术应用最新国际动态[J].无损探伤,2009,33(4):1-6. [8] 董旭.医用X射线数字摄影(CR/DR)系统检测方法的研究和评定[J].中国医学装备,2010,7(1):8-11. [9] 李衍.工业DR技术的新动向[J].无损探伤,2006,30(6):1-4. [10] 吴章勤,刘荣海,艾川,等.基于X射线数字成像技术的GIS尺寸标定[J].无损检测.2013,35(2):46-48. [11] 郭涛涛,王达达,于虹,等.变电站X射线检测的防护措施[J].无损检测.2013,35(5):30-33.
