钢制管塔腐蚀的超声导波检测

详细信息

Ultrasonic Guided Waves Testing of Steel Tube Tower Corrosion

摘要: 利用设计制作的模拟试块和对比试块，对钢管塔腐蚀进行了超声导波检测。通过导波在钢板中的端面传播特性、不同厚度钢管塔检测的探头选择、不同类型缺陷的定位定量，提出了检测工艺，并利用实际试样检测结果对其进行验证。结果表明，超声导波检测方法可用于钢管塔尤其是其埋地部分局部腐蚀的检测，所制订的检测工艺可以检出不小于钢管塔壁厚20%(最小深度2mm)的腐蚀坑。
- 钢管塔 /
- 腐蚀 /
- 导波检测
Abstract: Study was made of steel tube tower corrosion inspection by guided waves testing with the simulation and reference test blocks. The testing technology was developed by guided waves propagation character of the end face, probes choice of different tube thickness, and defect location and quantification. The results showed that ultrasonic guided waves testing technique was effective to the corrosion inspection，especially in the underground. The technology may detect the corrosion pit whose thickness was not more than twenty percent of wall thickness (the minimum depth of the corrosion pit was 2mm).
- Steel tube tower /
- Corrosion /
- Ultrasonic guided waves testing

[1]	何存富，李隆涛，吴斌.超声导波在管道中传播的数值模拟［J］.北京工业大学学报，2004,30(2)：129-133.
[2]	孙士彬,孙乾耀,DEMMA A,等.采用超声导波技术对埋地管道进行腐蚀缺陷的检测［J］.无损探伤,2007,31(4)：6-9.
[3]	钟丰平,叶宇峰,程茂,等.超声导波对不同类型管道腐蚀检测的适用性研究［J］.压力容器,2009,26(2)：11-15.
[4]	钟丰平,叶宇峰,程茂,等.导波技术检测管道腐蚀的适用性分析［J］.无损检测,2009,31(9)：673-676.
[5]	张春雷,马庆增,张超群.高压输电线塔锚杆腐蚀的电磁导波信号表征［J］.广东电力,2009,22(10)：31-34.
