基于FPGA的轮对踏面电磁超声在线检测系统

米武军; 康 磊; 王淑娟; 冯剑钊; 翟国富

基于FPGA的轮对踏面电磁超声在线检测系统

哈尔滨工业大学军用电器研究所, 哈尔滨 150001

基金项目:

铁道部科技研究开发计划重点课题资助项目(2009G018-E)

详细信息

作者简介:
米武军(1986-), 男, 硕士研究生, 主要从事基于电磁超声的无损检测研究。

中图分类号: TP23; TG115.28
计量
- 文章访问数: 2
- HTML全文浏览量: 0
- PDF下载量: 1
出版历程
- 收稿日期: 2009-08-13
- 刊出日期: 2010-07-09

On-Line EMAT Detecting System for Wheelset Tread Based on FPGA

摘要

摘要: 为了提高我国当前列车轮对的检测效率, 设计了一种基于FPGA的列车轮对踏面电磁超声在线检测系统。该系统将电磁超声检测技术与FPGA应用技术相结合, 采用基于FPGA的可编程片上系统技术, 实现了电磁超声信号发射/接收、数据采集、微弱信号检测以及存储显示等, 充分发挥了FPGA在运算速度和设计灵活性上的优势。试验表明, 系统具有较高的检测精度和检测效率, 可在列车运行速度<20 km/h时成功检测出轮对踏面上深度>2 mm的人工缺陷。
- 轮对踏面 /
- 电磁超声检测 /
- 微弱信号检测
Abstract: An on-line EMAT detecting system for wheelset tread based on FPGA was developed to improve the detecting efficiency of wheelset. Combining EMAT with SOPC technology based on FPGA, this system fully took advantage of FPGA in design flexibility and processing speed. It could achieve transmission and reception of the electromagnetic ultrasonic surface wave, data acquisition, weak signal detection, storage and display. Experiments showed that the system possessed high detecting accuracy and efficiency, which could detect an artificial defect that is deeper than 2 mm on wheelset tread when the trains speed was slower than 20 km/h.
- Wheelset tread’s defects /
- Electromagnetic ultrasound testing /
- Weak signal detection

HTML全文

参考文献(10)

[1]	MacLauchlan D, Clark S, Cox B. Recent advancements in the aApplication of EMATs to NDE[C]// 16th World Conference on NDT. Montreal, Canada: [s.n.], 2004.
[2]	王红, 彭亮, 于宗光.FPGA现状与发展趋势[J].电子与封装, 2007, 7(7): 32-37.
[3]	Clark A V, Schramm R E, Schaps S R. Safety assessment of railroad wheels through roll-by detection of tread cracks[C]// Proceedings of Society of Photo-Optical Instrumentation Engineers Conference on Nondestructive Evaluation of Aging Railroads. Oakland: [s.n.], 1995, 2458: 109-119.
[4]	Mian Z F, Peabody W, Haller T. Wheel Inspection System[P]. US: 6523411B1, 2003.
[5]	Salzburger H J, WANG L, GAO X R. In-motion ultrasonic testing of the tread of high-speed railway wheels using the inspection system AUROPA Ⅲ[C]// 17th World Conference on Nondestructive Testing. Shanghai: [s.n.], 2008.
[6]	范弘, 孙邦明, 沈明珠.火车车轮超声探伤技术研究与开发[J].钢铁, 2000, 35(12): 60-63.
[7]	彭建平, 王黎, 高晓蓉.基于EMAT技术的轮对踏面探伤仪[J].仪表技术与传感器, 2009(1): 18-20.
[8]	王淑娟, 赵再新, 翟国富.基于电磁超声的火车车轮裂纹检测系统[J].仪表技术与传感器, 2005(11): 28-29.
[9]	王淑娟, 康磊, 翟国富.电磁超声换能器的微弱信号检测[J].无损检测, 2007, 29(10): 591-592.
[10]	Kang L, Mi M J, Wang S J. Research on weak signal detection technique for electromagnetic ultrasonic inspection system[C]// The 3rd IEEE Conference on Industrial Electronics and Applications (ICIEA 2008). Singapore: [s.n.], 2008.
