长管拖车气瓶声发射检测技术

基金项目:

中央级科研院所科技基础性工作专项资金资助项目(Z00-J06)

详细信息

The Technique of Acoustic Emission Inspection of Cylinders of Tube Trailer

摘要: 为发现长管拖车气瓶实际使用中存在的裂纹、腐蚀等危险缺陷, 保障长管拖车的安全运行, 根据长管拖车气瓶结构、尺寸和材料特点, 制定了相应的声发射检测方案。加工了裂纹和腐蚀减薄等人工缺陷, 对长管拖车气瓶进行了整体声发射检测试验。模拟了裂纹、线腐蚀、点腐蚀和面腐蚀等四种不同缺陷的监测过程和定位结果, 并对这些声发射源的定位、分布和关联特性分别进行了分析。
- 长管拖车气瓶 /
- 声发射检测 /
- 人工缺陷
Abstract: In order to find the cracks, corrosion and other dangerous defects of in-service tube trailer gas cylinders, and to guarantee the safe operation of the tube trailer, corresponding acoustic emission testing program was worked out based on the tube trailer gas cylinders structure, size, material characteristics. Furthermore, corresponding cracks, corrosion thinning and other artificial defects were machined and the whole acoustic emission testing was perforwed to the tube trailer gas cylinders. This paper simulated the crack, line corrosion, pitting corrosion and surface corrosion defects in four different results of the monitoring process and positioning, and the characteristics of acoustic emission source location, distribution and associated features were analyzed.
- Tube trailer gas cylinders /
- Acoustic emission testing /
- Artificial defect

[1]	Fred F, Lyle Jr. Evaluation of the Effects of Natural Gas Contaminants on Corrosion in Compressed Natural Gas Storage Systems: Section 2\[M\]. U S: Southwest Research Institute, 1989: 6-19.
[2]	詹尚贤.CNG加气站建设中的几个问题\[J\].中国锅炉压力容器安全, 2002, 18(5): 12-14.
[3]	ASTM E 1419-00 Standard test method for examination of seamless, gas-filled, pressure vessels using acoustic emission［S］.
[4]	CGA C-18-1995 Methods for acoustic emission requalification of seamless steel compressed gas tubes［S］.
[5]	刘三江, 李邦宪, 郑晖.对长管拖车气瓶定期检验方法的探讨\[J\].中国锅炉压力容器安全, 2005, 21(2): 38-41.
[6]	刘三江, 沈功田, 李邦宪.长管拖车气瓶的无损检测技术\[J\].无损检测, 2005, 27(8): 418-422.
[7]	郑晖, 王勇, 刘三江.长管拖车气瓶声发射信号的传播衰减规律\[J\].中国特种设备安全, 2006, 22(11): 43-45.
