钢丝绳典型缺陷的漏磁场有限元仿真

基金项目:

深圳市科技研究基金资助项目(NSKJ-200709)

详细信息

Magnetic Flux Leakage of Typical Defect of Wire Rope Based on FE Simulation

摘要: 采用有限元仿真的方法, 分析了提离距离、缺陷宽度和深度以及缺陷在钢丝绳内的深度等参数与漏磁场的关系, 得出了提离距离并不是越小越好的结论; 并且缺陷宽度与提离距离的和等于漏磁场径向分量峰-峰值间距; 漏磁场轴向分量与缺陷深度近似成线性关系; 漏磁场轴向分量与缺陷在绳内深度成线性关系。
- 漏磁检测 /
- 钢丝绳 /
- 有限元方法 /
- 缺陷仿真
Abstract: Finite element simulation was used to analyze the relationship between MFL and the lift-offs, defects width, depth and in-rope depth. It concluded that lift-offs was not the smaller the better; the sum of defects width and lift-offs were equal to the distance of peak-peak at the radial part of MFL; the axial part of MFL and defect depth were in linear relation approximately, so were the defects in-rope depth.
- Magnetic flux leakage testing /
- Wire rope /
- Finite element method /
- Defect simulation

[1]	康宜华, 杨克冲, 朱文凯, 等.钢丝绳断丝断口漏磁场分析计算[J].中国机械工程,1993,4(4): 1-3.
[2]	杨叔子, 康宜华.钢丝绳断丝定量检测原理与技术[M].北京: 国防工业出版社,1995.
[3]	Cao Y N, Zhang D L, Wang C, et al. A novel electromagnetic method for local defects inspection of wire rope[A]. TENCON 2006. 2006 IEEE Region 10 Conference[C]. Hongkong: 2006.图11 不同绳内深度缺陷漏磁场分布
[4]	纪凤珠, 王长龙, 陈正阁, 等.基于三维有限元法的漏磁场分析[J].兵工学报,2007,28(7): 876-879.
[5]	李路明, 郑鹏, 黄松岭, 等.表面裂纹宽度对漏磁场Y分量的影响[J].清华大学学报(自然科学版),1999,32(2): 43-45.
[6]	仲维畅.工件表面沟槽深度对漏磁场的影响[J].无损检测,1997,19(11): 304-307.
