Measurement Error of Defect Orientation Parameters of TOFD Axis Deviation Detection
-
摘要: 在TOFD非平行扫查检测中, 是假定缺陷位于焊缝中心轴线上的。因此对于偏离焊缝中心轴线的缺陷, 其埋藏深度和自身高度这两个方位参数的测量存在一定的误差。通过数学推导, 建立了相应的数学模型, 从理论上分析了埋藏深度、自身高度、偏心距大小、探头入射点间距等多个因素对该误差影响的变化规律, 并通过试块进行了试验验证。结果证明减小埋藏深度及高度测量误差的方法对TOFD无损检测工艺的选择具有较好的指导意义。Abstract: It is assumed that the defect is located in the center of the weld in parallel scan by TOFD, so the measurement of orientation parametters such as depth and height has some errors as for the axis deviation defects in weld. Through accurate mathematical deduction, the article establishes detailed mathematical model so as to analyze the changes regulation of measurement error of depth and height by various factors (such as true depth, true height, axis deviation, probe center separation),and experimental verification by TOFD block is carried out; meanwhile, the article proposes the methods of reducing the measurement error, and they have great guiding significance for process selection of TOFD nondestructive testing.
-
-
[1] 2010 Asme BPVC V.2010 Asme boiler and pressure vessel code,section v nondestructive examination, appendix III-time of flight diffraction (tofd) technique.［S］. [2] J. P. CHARLESWORTH, J. A. G. Temple. Engineering applications of ultrasonic time of flight diffraction, second edition［M］Research Studies Press LTD,2001. [3] 迟大钊.基于超声TOFD法的焊缝缺陷表征研究检测与定量研究［D］.哈尔滨工业大学,2007. [4] CHEN T.L, QUE P.W, ZHANG Q, et al. Ultrasonic nondestructive testing accurate sizing and locating technique based on time-of-Flight-Diffraction method［J］. Russian Journal of Nondestructive Testing.2005,41(10):594-601. [5] 孙忠波,郑红霞,张平.TOFD检测中借助变型波确定缺陷偏心距及缺陷精确深度的探讨［J］.无损检测,2010,32(7):500-503+508. [6] MONDAL S, SATTAR T. An Overview of TOFD method and its mathematical model［J］.NDT(S0963-8695),2000,5(4): 58-63. [7] 曹玉雯.超声TOFD的缺陷检测与定量研究［D］.北京化工大学,2010. [8] 强天鹏.TOFD技术的检测盲区计算和分析［J］.无损检测,2008,30(10):738-741.
