Direct Current Potential Drop Inspection Technique for Metallic Foam
-
摘要: 为验证直流电位法检测泡沫金属缺陷孔洞及大小的有效性, 对实物泡沫金属进行了直流电位法无损检测试验。设计制作了具有不同大小缺陷的五个试件, 对各试件进行了恒流加载和表面电位分布测量, 并对所测结果进行了相应的差分及滤波处理, 以提高信噪比。同时, 为确定有效的试验条件, 运用有限元分析程序对电位检测信号进行了数值模拟。试验和数值结果表明, 对泡沫金属可以利用直流电位方法检出缺陷, 且缺陷大小和检测电位信号的大小有一定对应关系。这为泡沫金属缺陷的定量无损检测打下了基础。Abstract: In order to verify the validity of direct current potential drop(DCPD) inspection technique for inspecting the defects and its size in metallic foam, the real metallic foam inspection experiment by DCPD was conducted. Five specimens with defects of different sizes were fabricated. Direct current was loaded to the specimens respectively and the potentials on the middle line of the top surface of the specimens were measured. By making difference and filtering operation, the S/N ratio of the measured signals was improved. In addition, a numerical model was built to simulate the DCPD signals by using an FEM numerical code. Based on the experimental and the numerical results, it showed that the defect in the actual metallic foam could be detected by using DCPD technique, and the size of the defects depended on the amplitude of the potential signal, which laid a foundation for the quantitative NDT of the metallic foam.
-
Keywords:
- Metallic foam /
- Direct current potential drop /
- Finite element method
-
-
[1] 卢天健, 何德坪, 陈常青, 等.超轻多孔金属材料的多功能特性及应用[J].力学进展, 2006, 36(4): 517-518. [2] 李家伟, 陈积懋.无损检测手册[M].北京: 机械工业出版社, 2002: 2-4; 426. [3] Tada N, Naoya. Application of direct-current potential difference method to evaluation of various damages in conductive materials[C]. ASME 2008 Pressure Vessel and Piping Conference. USA: Chicago, 2008. [4] Tada N, Hayashi Y. Analysis on the applicability of direct current electrical potential method to the detection of damage by multiple small internal cracks[J]. International Journal of Fracture, 1997, 85(1): 1-9. [5] Ghajar R. An alternative method for crack interaction in NDE of multiple cracks by means of potential drop technique[J]. NDT&E International, 2004, 37(7): 539-544. [6] 解社娟.泡沫金属无损检测方法研究[D].西安: 西安交通大学, 2009. [7] 盛剑霓.工程电磁场数值分析[M].西安: 西安交通大学出版社, 1999. [8] 刘培生, 李铁藩.泡沫金属电阻率的计算方法[J].稀有金属材料与工程, 1999, 28(4): 19.
