The Application of Virtual Ultrasonic Field Based on AutoCAD Software in Ultrasonic Testing
-
摘要: 介绍了AutoCAD超声场模拟用于辅助超声波检测的方法，并针对复杂工件超声波检测的难点，将该方法应用于不同的工程实例。结果表明，基于AutoCAD的超声场模拟有助于复杂工件检测时的缺陷判定和提高检测效率。Abstract: A method of using simulative ultrasonic field to aid ultrasonic test based on Autocad software was introduced. Aiming to overcome the difficulty of complex workpieces ultrasonic testing, this method was applied in project. The results indicated that the method conduced to determinate defects and enhance the efficiency.
-
Keywords:
- AutoCAD software /
- Ultrasonic field /
- Analogue
-
-
[1] 张杰，周进，罗宏建.火力发电厂测温热电偶套管角焊缝质量的超声检测［J］.无损检测,2009(8):661-663. [2] DL/T 820—2002管道焊接接头超声波检验技术规程［S ］.
