长输管道的全自动超声检测耦合监控设置方式

详细信息

Setting mode of full automatic ultrasonic testing coupling monitoring forlong-distance transmission pipeline

1. Hebei Zhongyue Inspection and Testing Co., Ltd., Langfang 065000, China;
2. Beijing Smart Detection Consulting Co., Ltd., Beijing 100176, China;
3. National Pipeline Construction Project Management Branch, Langfang 065000, China

摘要: 通过设置人工耦合不良区域，对比长输管道全自动超声检测时的两种常用耦合通道设置方法，分析了耦合监控设置对实际检测结果有效性的影响。结果可为长输管道全自动超声检测耦合监控方案的选择以及参数设置提供参考。
- 全自动超声波检测 /
- 耦合监控 /
- 脉冲回波 /
- 一发一收
Abstract: The effects of coupling monitoring settings on the effectiveness of the actual test results were analyzed by setting the artificial poorly coupling areas and comparing the two common coupling channel methods in full automatic ultrasonic testing of long-distance pipeline. The research results can provide reference for the choice of coupling monitoring scheme and parameter setting of full automatic ultrasonic testing in long distance pipelines.
- full automatic ultrasonic testing /
- coupling monitoring /
- pulse echo /
- pitch-catch

[1]	袁少山. 管道自动焊与全自动超声波检测技术在西气东输管道工程中的应用[J].石油工程建设, 2004, 30(5):36-41.
[2]	胡安鑫, 苏欣, 孙华锋, 等. 国内外长输管道自动焊现状[J]. 天然气与石油, 2006, 24(2):12-18.
[3]	高永东, 赵海宴, 张宏洲. 管道自动焊技术在西气东输工程中的应用[J]. 油气储运, 2003, 22(12):53-55.
[4]	刁凤东, 滕毅, 张福强. CRC管道全自动焊接工艺的研究与应用[J]. 焊接技术, 2007, 36(6):57-58.
