塞焊叶轮磁粉检测异常磁痕显示分析

详细信息

Analysis of abnormal magnetic particle indications in magnetic particle testing ofplug welded impeller

摘要: 采用四大常规无损检测方法,并结合显微观察、金相分析以及机械性能检测等方法,对塞焊叶轮异常磁痕的性质、产生机理进行分析,并制定了判定磁痕显示性质的工艺流程,可提高塞焊叶轮焊缝的磁粉检测效率。
- 磁粉检测 /
- 渗透检测 /
- 金相组织 /
- 异常磁痕显示 /
- 非相关显示
Abstract: Four conventional nondestructive testing methods, combined with microscopic observation, metallographic analysis and mechanical property testing, are used to analyze the character and generation mechanism of abnormal magnetic particle indications on plug welded impeller. The technological process for determining the display properties of magnetic particle indications is developed, which can improve the magnetic particle testing efficiency of plug welded impeller welds.
- magnetic particle testing /
- penetrant testing /
- metallographic structure /
- abnormal magnetic particle indication /
- non-relevant indication

[1]	谭云华, 钱熙源.同种钢焊缝磁粉检测非相关显示的鉴别[J].无损探伤,2018,42(5):46-47.
[2]	于明明, 刘洪杰.贝氏体钢焊缝熔合线磁粉非相关显示试验分析及处理[J].机械,2018,45(增刊2):78-79.
[3]	王凌宇, 邹家生,朱治愿.层间温度对ENiCrMo-3镍基焊条熔敷金属组织及性能的影响[J].江苏科技大学学报,2021,35(6):24-25.
