Turbine blade crack detection based on ultrasonic infrared thermography
-
摘要: 使用等离子喷涂工艺对涡轮叶片喷涂镍铬铝钇涂覆层,采用超声红外热成像技术对喷涂前和喷涂后的涡轮叶片进行检测,可以检测到2处裂纹缺陷;采用渗透检测技术只能检测到喷涂前涡轮叶片的1处裂纹缺陷,无法检测出喷涂后涡轮叶片的裂纹缺陷;最后对喷涂后的涡轮叶片进行剖析和金相显微镜检测,发现2处裂纹缺陷,验证了超声红外热成像技术对含涂覆层涡轮叶片裂纹检测的有效性。对比试验表明,超声红外热成像技术可检测喷涂前和喷涂后涡轮叶片的裂纹缺陷。Abstract: The plasma spraying process was adopted to spray the turbine blade with NiCrAlY coating. ultrasonic infrared thermography technique was used to detect turbine blade before and after spraying and achieve two crack defect detection. The penetration detection technology can only detect one crack defect in the turbine blade before spraying and however cannot detect crack defects in the turbine blade after spraying. Finally, the turbine blade after spraying was dissected and detected by metallographic microscopy and two crack defects were found. It verified the effectiveness of ultrasonic infrared thermography for crack detection of turbine blade with coating layer. The comparison results show that ultrasonic infrared thermography can detect the crack defects in turbine blades before and after spraying.
-
-
[1] 于霞, 张卫民, 邱忠超, 等. 航空发动机涡轮叶片裂纹检测信号特征提取[J]. 兵工学报, 2014, 35(8):1267-1274. [2] 万利, 李舜酩, 金业壮. 某型发动机压气机第1 级整流叶片疲劳试验研究[J]. 航空发动机, 2008, 34(3):15-17. [3] 宋凯, 刘堂先,李来平,等.航空发动机涡轮叶片裂纹的阵列涡流检测仿真[J]. 航空学报, 2014, 35(8):2355-2363. [4] 许锷俊. 缺陷、损伤、微裂纹对航空发动机构件服役总寿命及可靠性的影响[J]. 航空发动机, 2003, 29(2):11-15. [5] 郭海鸥. 飞机某型发动机压缩机一级叶片裂纹检测研究[J]. 无损探伤, 2004, 28(5):45-46. [6] 冯强, 童锦艳, 郑运荣,等. 燃气涡轮叶片的服役损伤与修复[J]. 中国材料进展, 2012, 31(12):15. [7] 耿荣生, 郑勇. 航空无损检测技术发展动态及面临的挑战[J]. 无损检测, 2002, 24(1):1-5. [8] 孙护国, 霍武军. 航空发动机涡轮叶片的检测技术[J].航空发动机, 2002, 28(1):23-25. [9] 徐桂荣, 刘甜甜, 关雪松,等. 航空产品磁粉检测与渗透检测分析[J]. 兵器材料科学与工程, 2021, 44(6):124-128. [10] 苏清风, 习小文,石剑,等.铸造闭式叶轮内型面荧光渗透检测[J].失效分析与预防,2018,13(6):367-372. [11] 冯辅周, 张超省, 闵庆旭, 等. 超声红外热像技术中金属平板裂纹的生热特性[J].红外与激光工程, 2015,44(5):1456-1461. [12] 秦雷, 刘俊岩, 龚金龙, 等.超声红外锁相热像技术检测金属板材表面裂纹[J]. 红外与激光工程, 2013,42(5):1123-1130. [13] LI W, YUAN X A, CHEN G M, et al.High sensitivity rotating alternating current field measurement for arbitrary-angle underwater cracks[J]. NDT&E International, 2016,76:123-131.
[14] 寇光杰, 杨正伟,贾庸,等.复杂型面叶片裂纹的超声红外热成像检测[J].红外与激光工程,2019,48(12):1-9.
