Magnetic flux leakage nondestructive testing with large lift-off
-
摘要: 漏磁检测是一种重要的无损检测方法，广泛应用于石油、钢铁等行业。在漏磁检测中，提离值是最重要的工艺参数之一。就保护探头或曲面检测的角度而言，通常传感器与工件之间始终保持一定的提离值，但漏磁场随提离值的增大会迅速衰减，降低了检测的灵敏度和信噪比。因此如何实现大提离下的高精度漏磁检测，一直以来都是研究的热点。首先探讨了提离值的定义及提离值对漏磁信号的影响；归纳了信源、传递介质以及传感器这3个大提离检测的要素，并根据这3个要素，总结归纳了目前国内外学者提出的诸多大提离漏磁检测方法并介绍了基于转变检测对象的大提离检测方法；最后讨论了大提离漏磁检测方法目前仍存在的问题以及其发展趋势。Abstract: Magnetic flux leakage testing is an important nondestructive testing method, which is widely used in petroleum, steel, and other industries. In magnetic flux leakage detection, the lift-off value is one of the most important parameters. Generally, from the perspective of protecting the probe or curved surface detection, a certain lift-off value needs to be maintained between the sensor and the workpiece. However, the leakage magnetic field decays rapidly with the increase of lift-off value, which reduces the sensitivity and signal-to-noise ratio of detection. Therefore, how to make the sensor realize high-precision magnetic flux leakage detection under large lift-off has been an important research focus. Firstly, this paper discusses the definition of lift-off value and introduces the influence of lift-off value. Secondly, three elements of large lift-off detection are summarized. They are the source, transmitting medium, and sensors. According to the above influencing factors, many magnetic flux leakage detection methods proposed by domestic and foreign scholars are summarized. In addition, the method based on transformation detection object is also introduced. Finally, the existing problems and the development trend of large lift-off magnetic flux leakage detection methods are discussed.
-
-
