高压电缆附件铅封缺陷的交流电磁场检测

详细信息

Alternating current field measurement for lead seal defects of high voltage cable accessories

1. Jining Luke Testing Equipment Co., Ltd., Jining 272000, China;
2. Jining Special Equipment Inspection and Research Institute, Jining 272000, China

摘要: 铅封是高压电缆常用的连接方式，受外部热缩套及防水带干扰的影响，常规检测方法难以对内部铅封连接状态进行检测。制备了高压电缆铅封试样并加工了相应缺陷，以模拟现场使用状况，采用交流电磁场检测技术进行了检测试验。试验结果表明，交流电磁场检测技术能够穿透保护层对铅封表面开裂缺陷进行检测，检测灵敏度及分辨力较高，但检测结果会受到探头角度的影响，检测时需考虑检测方向。
- 交流电磁场检测技术 /
- 铅封 /
- 高压电缆 /
- 缺陷模拟
Abstract: The lead sealing is a common way of connecting high-voltage cables. Due to the interference of external heat-shrinkable sleeves and waterproof tapes, conventional inspection methods are difficult to inspect the internal lead seal connection status. Simulate onsite use conditions and process defects to prepare high-voltage cable lead seal samples. Carry out inspection experiments based on alternating current field measurement(ACFM)technology at the same time. Testing results shows that ACFM can penetrate the protective layer to detect the surface cracking defects of the lead seal. The detection sensitivity and resolution are better than other methods. The detection direction should be considered when detecting because the detection result will be affected by the angle of the probe.
- ACFM /
- lead sealing /
- high-voltage cable /
- defect simulation

[1]	惠宝军,傅明利,刘通,等.110 KV及以上电力电缆系统故障统计分析[J].南方电网技术,2017,11(12):44-50,67.
[2]	曹俊平,王少华,蒋愉宽,等.浙江电网高压电缆线路运行情况分析[J].电线电缆,2017(3):39-43.
[3]	方春华,胡冻三,郭凯歌,等.高压电缆终端铅封缺陷超声检测方法研究[J].中国测试,2021(3):1-5.
[4]	蒲英俊,刘广兴,李正利,等.涡流检测高压电缆附件铅封缺陷的试验研究[J].山东电力技术,2020,47(2):56-60,69.
[5]	李兵,于亮.交流电磁场检测技术在压力容器焊缝检测中的应用[J].中国特种设备安全,2016,32(4):47-50.
[6]	REN S K,ZHU Z B,LIN T H,et al.Design for the ACFM sensor and the signal processing based on wavelet de-noise[C]//2009 2nd International Congress on Image and Signal Processing.Tianjin,China.IEEE,2009:1-4.
[7]	李伟.基于交流电磁场的缺陷智能可视化检测技术研究[D].青岛:中国石油大学,2007.
[8]	ZHOU J W,LUGG M C,COLLINS R.A non-uniform model for alternating current field measurement of fatigue cracks in metals[J].International Journal of Applied Electromagnetics and Mechanics,1999,10(3):221-235.
