Eddy current pulse thermography testing of metal surface defects
-
摘要: 利用搭建的电涡流脉冲热成像检测平台，对常用金属的表面缺陷进行了检测。为了去除热成像图中的噪声，提高金属试件表面缺陷的对比度，采用独立成分分析法分析了表面缺陷的热响应特征。结果表明，独立成分分析法可有效地识别出缺陷、线圈、缺陷及线圈附近、试件边缘等区域的热响应信号特征，缺陷区域成像清晰，实现了金属构件表面线性缺陷和微小开孔的可视化检测。Abstract: The built-up eddy current pulse thermal imaging inspection platform was used to detect the surface defects of common metals. In order to remove the noise interference in the thermal image and improve the contrast of the surface defects of the metal specimen, the independent component analysis method was used to analyze the thermal response characteristics of the surface defects. The results show that the independent component analysis method can effectively identify the thermal response signal characteristics of the defect area, the coil area, the defect and the area near the coil, the edge area of the test piece, etc. The visual inspection of openings defect area is imaged clearly, and the linear defect and the small surface of the metal component are realized.
-
-
[1] CHENG L, TIAN G Y. Surface crack detection for carbon fiber reinforced plastic (CFRP) materials using pulsed eddy current thermography[J]. IEEE Sensors Journal, 2011, 11(12):3261-3268.
[2] ZENZINGER G, BAMBERG J, SATZGER W, et al. Thermographic crack detection by eddy current excitation[J]. Nondestructive Testing and Evaluation, 2007, 22(2/3):101-111.
[3] WILSON J, TIAN G Y, MUKRIZ I, et al. PEC thermography for imaging multiple cracks from rolling contact fatigue[J]. NDT & E International, 2011, 44(6):505-512.
[4] CHUN Y, TING X, XUE G H, et al. Research on damages evaluation method with multi-objective feature extraction optimization scheme for M/OD impact risk assessment[J]. IEEE Accesss, 2019, 7:98530-98545.
[5] 白利兵. 电涡流脉冲热成像无损检测技术研究[D]. 成都:电子科技大学, 2013. [6] 周乃望. 金属亚表面缺陷脉冲涡流热成像检测研究[D]. 青岛:中国石油大学(华东), 2016. [7] 朱佩佩, 程玉华, 白利兵, 等. 脉冲涡流红外热成像缺陷特征提取方法[J]. 电子科技大学学报, 2019, 48(5):741-746. [8] 王晓杰. 脉冲涡流热成像检测技术中的图像增强方法研究[D].成都:电子科技大学,2020. [9] 宋远佳, 张炜, 金国锋, 等. 基于独立分量分析的红外热波无损检测图像增强[J]. 无损检测, 2011, 33(9):49-53. [10] 杨瑞珍, 杜博伦, 何赟泽. 晶体硅光伏电池电磁感应激励红外热辐射缺陷检测与成像技术[J]. 电工技术学报, 2018, 33(2):321-330.
