压气机叶片根部原位检测传感器的设计与制作

基金项目:

国家自然科学基金资助项目（51565043，51765048）；江西省教育厅科学技术研究资助项目（GJJ160698）

详细信息

Design and Fabrication of Eddy Current Testing Sensors for Compressor Blade Roots

Key Laboratory of Nondestructive Testing, Ministry of Education, Nanchang Hangkong University, Nanchang 330063, China

摘要: 在外场航空维修中，发动机叶片根部原位探伤时存在涡流检测传感器适用性不强、灵敏度低、可达性差的难题。基于涡流环理论，结合压气机叶片根部的形状特点，对传感器的磁芯检测面进行加工制作，设计与叶片根部吻合度高的仿形涡流检测传感器，实现对叶片根部疲劳裂纹缺陷的原位检测。试验结果表明：新设计的仿形传感器能够消除因为叶片根部形状不规则带来的提离影响，且传感器稳定性好、灵敏度高。
- 叶片根部 /
- 涡流传感器 /
- 设计与制作
Abstract: When the aircraft is inspected and repaired at the field, the eddy current testing sensor has the problems of poor applicability, low sensitivity and poor accessibility when inspecting the engine blade root in-situ. In order to detect the fatigue crack defect on the root of the blade, in this paper, the core detection surface of sensor is processed and a profiled eddy current detection sensor with a high degree of coincidence with the root of the blade is designed, based on the swirl ring theory and the shape characteristics of the root of the compressor blade. The experimental result shows that the newly designed profiling sensor can eliminate the lift-off effect because of the irregular shape of the blade root, and the sensor has good stability and high sensitivity.
- the root of the blade /
- eddy current sensor /
- design and fabrication

[1]	ARAKERE N K, SWANSON G. Fretting stresses in single crystal superalloy turbine blade attachments[J]. Journal of Tribology, 2001, 123(2):413-423.
[2]	ARAKERE N K, KNUDSEN E, SWANSON G R, et al. Subsurface stress fields in face-centered-cubic single-crystal anisotropic contacts[J]. Journal of Engineering for Gas Turbines & Power, 2006, 128(4):879-888.
[3]	任吉林, 林俊明, 高春法. 电磁检测[M]. 北京:机械工业出版社,2000.
[4]	单成祥. 传感器的理论与设计基础及其应用[M].北京:国防工业出版社,1999.
[5]	孙金立, 陈新波, 袁海跃. 放置式探头检测工件时特征频率的计算[J]. 无损检测, 2001, 23(5):185-189.
[6]	于亚婷, 杜平安. 含铁氧体磁芯的电涡流传感器线圈阻抗理论模型和数值计算[J]. 仪器仪表学报, 2007, 28(12):2267-2273.
[7]	谭祖根, 陈守川. 电涡流传感器的基本原理分析与参数选择[J]. 仪器仪表学报, 1980(1):116-125.
[8]	谭维, 王长振, 周甘宇,等. 高磁导率锰锌铁氧体材料研究现状[J]. 中国锰业, 2002, 20(1):33-36.
[9]	任吉林, 林俊明, 高春法. 电磁检测[M].北京:机械工业出版社,2000.
