加热参数对表面温度信号的影响的建模与分析

刘颖韬, 郭兴旺, 郭广平

刘颖韬, 郭兴旺, 郭广平. 加热参数对表面温度信号的影响的建模与分析[J]. 无损检测, 2009, 31(7): 534-537.
引用本文: 刘颖韬, 郭兴旺, 郭广平. 加热参数对表面温度信号的影响的建模与分析[J]. 无损检测, 2009, 31(7): 534-537.
LIU Ying-Tao, GUO Xing-Wang, GUO Guang-Ping. Modeling and Analysis of the Influence of Heating Parameters on Surface Temperature Signals[J]. Nondestructive Testing, 2009, 31(7): 534-537.
Citation: LIU Ying-Tao, GUO Xing-Wang, GUO Guang-Ping. Modeling and Analysis of the Influence of Heating Parameters on Surface Temperature Signals[J]. Nondestructive Testing, 2009, 31(7): 534-537.

加热参数对表面温度信号的影响的建模与分析

详细信息
    作者简介:

    刘颖韬(1976-), 男, 工学硕士, 工程师, 主要从事机械设计和红外热像无损检测技术研究。

  • 中图分类号: TG115.28

Modeling and Analysis of the Influence of Heating Parameters on Surface Temperature Signals

  • 摘要: 为了研究加热参数(包括加热时间、热流密度和加热量)对表面温度信号的影响, 使用有限元法对二维和三维模型进行了仿真分析, 得出了以下结论: 有缺陷区与无缺陷区的最大温差主要受加热量的影响, 随加热量的增加而增大; 最大温度对比度及其出现时间和有缺陷区与无缺陷区的最大温差出现时间对热流密度的改变不敏感, 但是会受到加热时间的影响; 对于碳纤维增强塑料, 最大温度对比度表现出较强的稳定性, 说明该参数更能够反映出缺陷本身的特征, 有助于缺陷的定量计算; 对于铝类热扩散率高的材料, 高热流密度和短时加热是一种更为合适的加热方式。
    Abstract: To study the influence of heating parameters, including heating pulse duration, heat flux density and heating energy, on surface temperature signals, a 2D model for carbon fiber reinforced plastic sample and a 3D model for aluminum sample were investigated and solved by finite element method(FEM). Calculation results showed that the differential temperature between defect and sound areas depended on heating energy, and it got greater while the heating energy increasing. Maximum temperature contrast, differential temperature peak time and best observation time were less sensitive to the change of heat flux density, but affected by heating pulse duration. Maximum temperature contrast was less affected by heating parameters when materials were carbon fiber reinforced plastics(CFRP), so it had more relations to defects and could be used for quantitative analysis of defects. Great heat flux density and short heating pulse was a better choice for detecting defects in metal materials with greater thermal diffusivity, such as aluminum.
  • [1] Galietti U, Ladisa S, Pappalettere C, et al. Hybrid procedure to characterize hidden defects in composite[J]. Thermosense XXIV SPIE, 2002, 4710: 599-609.
    [2] Vladimir P Vavilov. Accuracy of thermal NDE numerical simulation and reference signal evalutions[J]. Thermosense-XXI SPIE, 1999, 3700: 14-19.
    [3] Vladimir P Vavilov. Three-dimensional analysis of transient thermal NDT problems by data simulation and processing[J]. Thermosense XXII SPIE, 2000, 4020: 152-163.
    [4] Robin Steinberger, Thomas Grünberger, Paul O Leary. Simulations and analytical models for optimization of photothermal surface crack detection[J]. Thermosense XXIII SPIE, 2001, 4360: 524-533.
    [5] Vladimir P Vavilov, Douglas Burleigh, Alexey G Klimov. Advanced modeling of thermal NDT problems: from buried landmines to defects in composites[J]. Thermosense XXIV SPIE, 2002, 4710: 507-521.
    [6] 王艳武, 杨立, 孙丰瑞.材料内部热阻热容型缺陷的红外检测模拟研究[J].激光与红外, 2006, 36(8): 657.
    [7] 肖劲松, 严天鹏.风力机叶片的红外热成像无损检测的数值研究[J].北京工业大学学报, 2006, 32(1): 48.
    [8] 赵石彬, 赵佳, 张存林, 等.红外热波无损检测中材料表面下缺陷类型识别的有限元模拟及分析[J].应用光学, 2007, 28(5): 559-563.
    [9] 李大鹏, 杨治东, 孙丰瑞.有限元方法在单面热流加热红外无损检测中的应用[J].机电工程, 2005, 22(2): 24.
    [10] 李大鹏, 张利群, 赵岩松.红外无损检测中的裂纹特征提取和图形重建方法研究[J].计算机测量与控制, 2005, 13(7): 624-626.
    [11] 黄红梅, 魏臻.红外无损检测的三维有限元仿真[J].安徽工业大学学报, 2006, 23(3): 313-314.
    [12] 李国华, 赵会友, 朱红秀, 等.红外热像检测的数值优化[J].煤矿机械, 2004, (9): 23-24.
    [13] 范春利, 孙丰瑞, 杨立.缺陷表面温度分布及空腔自然对流对红外检测的影响[J].激光与红外, 2005, 35(7): 504-507.
    [14] Sergio Marinetti, Alberto Muscio, Paolo Giulio Bison, et al. Modeling of thermal non-destructive evaluation techniques for composite materials[J]. Thermosense XXII SPIE, 2000, 4020: 164-173.
    [15] Bison P G, Bressan C, Cavaccini G, et al. NDE of composite materials by thermal method and shearography[J]. Thermosense-XIX SPIE, 1997, 3056: 220.
    [16] 杨世铭, 陶文铨.传热学[M].北京: 高等教育出版社, 1998: 420-424.
