Simulation of Oil Casing Pulsed Eddy Current Testing Based on Nonlinear Magnetic Conductivity
-
摘要: 根据有限元方法，建立了考虑磁导率非线性条件下的脉冲涡流检测系统瞬态数学模型；在磁导率非线性条件下，对不同激励电流下的油套管脉冲涡流检测过程进行了仿真。通过对每一时刻的磁导率进行迭代计算，得到更为精确的求解结果。利用该模型，获得了不同激励电流下4 mm腐蚀深度时所产生的脉冲涡流信号检测结果。根据仿真计算检测结果，发现由于材料磁导率非线性特点的存在，加大激励电流并不一定能提高检测灵敏度。Abstract: According to the principle of 2D electromagnetic finite element analysis, a transient mathematic model of pulsed eddy current(PEC) testing system considering permeability nonlinear was established and simulation research for oil casing PEC testing process of different drive current was conducted in permeability nonlinear. Through the iterative calculation to permeability by every moment, more accurate results were obtained. Using this model, we achieved the PEC signals detection results corresponding to the different excitation current in 4 mm corrosion depth. According to the test results, we found that due to the material permeability nonlinear, increasing excitation current does not necessarily improve the detection sensitivity.
-
Keywords:
- Pulsed eddy current /
- Magnetic conductivity /
- Nonlinear /
- Excitation current /
- Detection sensitivity
-
-
[1] 徐志远，武新军.激励参数和试件电磁参数对脉冲涡流检测影响的仿真分析［J］.无损检测,2008,32(1):1-4. [2] 辛伟.工业管道腐蚀脉冲涡流检测传感器仿真研究［D］.太原：中北大学,2009. [3] 徐志远，武新军，黄琛，等.有限厚铁磁性试件脉冲涡流响应研究［J］.华中科技大学学报,2011,39(6):91-95. [4] 谢德馨.三维涡流场的有限元分析［M］.第二版.北京：机械工业出版社,2007. [5] 张倩，胡仁喜，康士延，等.ANSYS12.0电磁学有限元分析［M］.北京:机械工业出版社,2010. [6] 余付平，朱荣新，王韫江，等.基于ANSYS的管道腐蚀缺陷有限元仿真［J］.计算机测量与控制,2009,17(1):151-153. [7] 林俊明，林发炳，林春景.隔热层下钢管壁厚脉冲涡流检测系统［J］.无损探伤,2006,30(6):26-30. [8] TAI C C, ROSE J H, MOULDER J C. Thickness and conductivity of metallic layers from pulsed eddy current measurements［J］. Rev. Sci. Instrum,1996,67(11):3965-3972. [9] GIGURE S, LEPINE B A, DUBOIS J M S. Pulsed eddy-current (PEC). characterization of material loss in multi-layer structures［J］. Canadian Aeronautics and Space Journal,2000,46(4):204-208.
