基于2D投影的BGA焊点X射线检测缺陷图像处理方法

详细信息

BGA Solder Joint Defects Image Processing Method Based on 2D Imaging by Radiographic Real Time Testing

摘要: 讨论了BGA封装器件焊接的特点, 并对BGA封装器件焊点检测方法进行了阐述。采用X射线检测法, 通过图像处理技术检测每个焊点的面积、质心和圆度, 以此来判断焊点是否有漏焊、焊锡球、桥连、焊球过大或过小、偏移以及焊球变形等缺陷。试验证明, 所用系统可以快速、准确地检测出BGA封装器件中常见的焊点缺陷, 为BGA封装器件焊点的质量提供保障。
- X射线实时成像 /
- BGA焊点 /
- 图像处理
Abstract: The soldering characteristics of BGA package components were discussed and the inspection methods used in the BGA package components were summarized.The X-ray detection was used, then the area, centroid coordinate and roundness of each solder ball could be accurately estimated by using of the image processing technology. Hence, the defects of BGA solder joint, such as missing ball, extra ball, ball bridging, oversize or undersize, offset and deformation could be detected. The experiment proved that the system could fast and accurately detect the familiar defects of the BGA package components and guarantee the quality.
- Radiographic real time imaging /
- BGA solder joint /
- Image processing

[1]	禹胜林, 王听岳, 崔殿亭.球栅阵列(BGA)封装器件与检测技术[J].电子工艺技术, 2000, 21(1): 11.
[2]	胡永芳, 徐玮, 禹胜林, 等.BGA封装器件焊点缺陷X射线检测法[J].电子工艺技术, 2005, 26(6): 340.
[3]	Wen-Yen Wu, Chih-Chung Chen. A system for automated BGA inspection[C]. Confercence on Cybernetics and Intelligent Systems. Singapore, [s.n], 2004.
[4]	曾祥照.X射线实时成像检测技术现场测评方法[J].无损探伤, 2000, 24(5): 27.
[5]	曾祥照, 张正荣.X射线数字化实时成像检测新技术[C].2006年西南地区第九届NDT学术年会暨2006年全国射线检测新技术研讨会论文集.重庆: [出版社不详], 2006.
