Ultrasonic Testing of the T-Shaped Root of Turbine Blade by Longitudinal Wave
-
摘要: 汽轮机的叶片是汽轮机的主要部件, 而叶片叶根的完整性关系到机组的安全稳定运行。为了检测T型叶根的完整性, 利用有限元计算软件对T型叶根的受力状况进行分析, 从而判定T型叶根的应力集中部位, 确定超声导波重点检查的位置。并且利用超声波探伤原理和自行设计的小角度微型纵波斜探头, 提出利用超声纵波对汽轮机T型叶根进行检测的方法, 并进行了试验分析, 证明汽轮机T型叶根的超声纵波检测是一种较为理想的探伤方法。Abstract: Turbine blades are the main turbine components, the integrity of whose roots are related to the safe and stable operation of the unit. In order to test the integrity of the T-shaped leaves roots, stress analysis of the T-shaped leaves roots was performed by the finite-element computing software to define the location of the stress concentration and the ultrasound examination. The ultrasonic testing method on the T-shaped Root of Turbine Blade was put forward with law detection principle of ultrasonic, and through the self-designed micro longitudinal wave angle probe been self-designed, the experimental analysis was carried out. It was concluded that the ultrasonic testing method of the T-shaped Root of Turbine Blade by longitudinal ware was ideal.
-
-
[1] 韩中合, 田松峰, 马晓芳, 等.火电厂汽轮机设备及运行[M].北京: 中国电力出版社, 2002: 51-63. [2] 李克明.超声波探伤[M].北京: 电力工业出版社, 1980: 270-282. [3] 马庆增, 冯活河, 黄建冲.有限元应力分析在叶根超声波探伤上的辅助应用[J].广东电力, 2000, 15(1): 300-306. [4] 刘志江, 袁平, 蔡礼东.一台300MW汽轮机次末级叶片断裂损伤原因分析[J].中国电力, 2000, 33(6): 7-10. [5] 宋绍河.汽轮机叶根新型超声波探头的研制[J].甘肃电力, 1994(2): 43-45. [6] 路正基, 王兴明.汽轮机叶片T形叶根裂纹的检测[J].无损探伤, 1989(4): 14-16. [7] 江学荣, 杜好阳.无缝钢管超声导波检测技术[J].广东电力, 2002, 15(5): 33-35. [8] 林德源, 陈开路, 陈秉忠.汽轮机叶片T形叶根的超声横波探伤[J].无损探伤, 2005, 27(10): 556-558. [9] DL/T 714—2000 汽轮机叶片超声波检验技术导则[S].
