Application of Ultrasonic Phased Array Technology in Tube Detection
-
摘要: 针对管材检测中常规超声波探伤设备稳定性差、检测效率低、探伤时声束灵活性差、信噪比低等问题，研究了超声相控阵技术在管材检测中的应用方法，并研制出一套管材超声相控阵在线检测系统。该系统拥有6套发射接收及采集处理板，每套拥有16个独立通道，共96个发射接收及采集通路。系统还拥有一套超声相控阵在线检测系统显示控制软件，能够以多种成像方式实时显示检测结果并报警。通过对两种不同尺寸的无缝钢管进行了试验分析，结果表明该试验系统具有高效、灵活和可靠等优点。Abstract: An ultrasonic phased array testing system was presented and developed for tube detection, as the conventional testing equipment usually encountered the unsteadiness, low SNR and low detection efficiency. The system has six sets of transmitting and receiving boards and collecting and processing boards. Each set has 16 independent channels. There are 96 channels totally. The system also has a set of ultrasonic phased array control and display software, which can display the test results in a variety of imaging modalities instantly. The experiment analyses have been carried out with two different sizes of the tubes. It shows that the system has high efficiency, flexibility, reliability, and other advantages.
-
Keywords:
- Nondestructive testing /
- Ultrasonic phased array /
- Tube detection
-
-
[1] 张碧星.超声相控阵聚焦与扫描方法研究［J］.声学技术,2010,29(6):22-23. [2] SHI C W, SHI Y J. Optimum beam steering of linear phased arrays［J］. Wave Motion,1999,29:245-265. [3] 师芳芳，孔超，张碧星.超声凹面相控阵列及其应用［J］.声学技术,2010,29(6):448-449. [4] 师芳芳.曲面超声相控阵聚焦与成像特性研究［D］.北京：中国科学院声学研究所,2009. [5] 中国机械工程学会无损检测分会.超声波检测［M］.北京：机械工业出版社,2000.
