On-Line Monitoring of High-Temperature Pipe Corrosion
-
摘要: 介绍了超声导波检测技术的理论基础，指出了这一技术用于在线监测的原理。利用该技术对炼油厂催化装置7条高温管道的腐蚀状况实施了在线监测，举例03-13管线三次监测情况及其数据的对比分析，得出基于磁致伸缩效应的超声导波技术可以实现高温管道腐蚀的在线监测。此外,还指出目前管道超声导波监测技术应用中存在的问题并提出了展望。Abstract: The theory of ultrasound guided wave detection and the principle of using guided wave on on-line monitoring were introduced. At the same time, we made use of the guided wave on 7 high temperature pipes in catalytic cracking unit, and took pipe 03-13 as an example to monitor its corrosion and analyze the data. Finally, conclusions were drawn that the magnetostrictive effect based guided wave technology allowed the monitoring of high temperature corrosion of pipe-line. In addition, the paper pointed out problems faced by ultrasonic guided wave monitoring technology and overviewed its future development.
-
Keywords:
- Ultrasonic guided waves /
- High-temperature pipe /
- Corrosion monitor
-
-
[1] 焦敬品，何存富，吴斌，等.管道超声导波检测技术研究进展［J］.实验力学,2002(1):1-9. [2] 李衍.埋管超声导波长距离检测新技术［J］.无损探伤,2004(1):1-5. [3] Kim Ji Yoon, Lee Dong Hoon, Park Kyo Shik. Long range inspection of city gas pipeline using ultrasonic guided waves［C］. 12th A-PCNDT 2006 – Asia-Pacific Conference on NDT,2006. [4] Cheong Y M, Lee D H, Jung H K. Ultrasonic guided wave parameters for detection of axial cracks in feeder pipes of PHWR nuclear power plants［J］. Ultrasonics,2004,42(1-9):883-888 (2004). [5] 何存富，李隆涛，吴斌.超声导波在管道中传播的数值模拟［J］.北京工业大学学报,2004(2):5-7. [6] 李隆涛，何存富，吴斌.管道长距离超声导波模态频散现象的抑制方法研究［J］.数据采集与处理,2004(3):1-6.
