管子-管板焊接接头射线数字成像自动检测系统

基金项目:

国家“十一五”科技支撑计划资助项目(2006BAK02B01)

详细信息

Digital Radiographic Imaging and Automatic Detection System for Welded Joint of Tube and Tube Sheet

摘要: 针对列管式换热器和列管式反应器管子-管板焊接接头特点, 研制了特殊的射线数字成像自动检测系统。分析了系统的检测原理, 并对系统的总体设计作了简要介绍。通过相关试验表明, 该系统运行平稳, 快速方便, 减少了常规射线检测对环境的污染, 极大地提高了工作效率。
- 管子-管板焊接接头 /
- 射线数字成像 /
- 自动检测
Abstract: Aiming at the character of welded joint of tube-tube sheet in multitubular heat exchanger and reactor, a special radiographic imaging and automatic detection system was designed. The principle of system was analysed, and the overall design was briefly introduced. Through the related experiment, it was indicated that the system ran steadily fast and conveniently, environment pollution of common radiographic testing was reduced, and the work efficiency was significantly improved.
- Welded joint of pipe-pipe sheet /
- Radiographic imaging /
- Automatic detecting

[1]	李衍.压力容器无损检测-射线检测技术(Ⅱ)[J].无损检测, 2004, 26(3): 132.
[2]	姚炫东, 王元华.热交换器管子-管板角焊缝的射线检测[J].无损检测, 2003, 25(12): 647.
[3]	林树青, 丁克勤, 寿比南.管子-管板焊接接头γ射线数字成像自动检测系统: 中国, CN200710122024[P].
