Application of Infrared Thermography to the Online Monitoring of Machining Process
-
摘要: 红外热成像技术可以测量被测目标的温度场分布,并以图像的形式表示出来。采用红外热成像方法对炸药代用药的机加切削过程的温度进行监测,得到了不同切削速率、切削进深以及有无孔洞缺陷等因素对工件温升的影响规律。试验表明:红外热成像技术可以非接触、实时监测炸药件加工过程的温度场分布并分析温度变化规律,为弹药加工安全性提供了参考。Abstract: Infrared thermography is a non-destructive testing technology that can be applied to determine the superficial temperature of objects. In this article, the machining process of mock explosive part is online monitored and the influence rules of temperature rise are obtained including the cutting velocity, cutting depth and void defect. The results indicate that infrared thermography can be used to monitor the temperature distribution of explosive parts during machining process and the change rule of temperature can be analyzed for the reference of safety of ammunition machining.
-
Keywords:
- Infrared technology /
- Temperature /
- Machining /
- Monitoring
-
-
[1] 杨晶,BEHNIA M, MORRISON G. 应用红外热成像仪测量电子元件正常工作条件下的表面温度[J]. 红外技术. 2002, 24(3):44-48. [2] BOYLE R J, SPUCKLER C M, LUCCI B L, et al. Infrared low temperature turbine vane rough surface heat transfer measurements [J].ASME Journal of Turbomachinery. 2001,123(1):168-177. [3] SWEENEY P C, RHODES J F. An infrared technique for evaluating turbine airfoil cooling designs[J].ASME Journal of Turbonmachinery. 2000,122(1):170-177. [4] 张明,曾令可.火焰温度场的红外热成像动态测试[J].激光与红外,1997,27(5):288-291. [5] 陈东生,李尚政.红外测温仪在车削工件温度场监测中的应用.传感器技术,2002,21(10):55-58.
