厚度小于6mm的搅拌摩擦焊焊缝相控阵超声检测

详细信息

Phased array ultrasonic testing for friction stir welding with weld thickness less than 6 mm

摘要: 介绍了一种用于厚度小于6 mm的搅拌摩擦焊（FSW）焊缝的相控阵超声检测方法。通过大量试验，基于实际的检测结果数据，对相控阵探头参数、楔块、扫描角度、扫描方式和显示方式等进行了研究，具有一定的可操作性，可进一步提高检测的质量。此方法操作方便，能够有效地节省时间，提高产能，且安全环保，具有较高的实际应用价值。
- 搅拌摩擦焊 /
- 相控阵超声检测 /
- 探头参数 /
- 扫描角度 /
- 扫描方式
Abstract: This paper introduces a phased array ultrasonic testing method for friction stir welding (FSW) with weld thickness less than 6 mm. Through a large number of tests and based on the actual test result data, the probe parameters, wedge block, scanning angle, scanning mode and display mode of phased array probe are explored, which has certain operability and can further improve the quality of detection. The method is convenient to operate and it can effectively save time and improve production. It is also capacity, safe and friendly to the environment and has high practical application value.
- friction stir welding (FSW) /
- phased array ultrasonic testing /
- probe parameters /
- scanning angle /
- scanning mode

[1]	冯聪. 开放式结构换热器管子管板焊缝氦检漏新型检测装置的应用[J]. 压力容器,2012,29(12):71-75.
[2]	丁训慎. 核电站蒸汽发生器制造和停堆期间的泄漏检验[J].无损检测,2009,31(2):159-161.
[3]	周胜. 氦检漏技术在核电站蒸发器传热管密封性试验中的应用[J].核科学与工程,2017,37(5):818-819.
[4]	吴孝检. 泄漏检测[M].北京:机械工业出版社,2005.
