基于虚拟仪器的钢管在线自动超声检测系统

详细信息

On-line Automatic Ultrasonic Testing System for Steel Pipe Based on the Virtual Instrument

摘要: 在虚拟仪器的开发理念下, 结合目前常规的超声检测方法, 提出了基于虚拟仪器的钢管在线自动超声检测系统。主要从机械设计、电气控制和上位机超声检测仪器三个方面对系统做了简单介绍。该系统的上位机超声检测仪器部分开发周期短、效率高, 软件编程灵活, 可以根据需要随时进行改进, 为方便实现钢管在线自动超声检测图像化结果显示奠定了基础。
- 虚拟仪器 /
- 超声检测 /
- 钢管
Abstract: The on-line automatic ultrasonic testing(UT) system for steel pipe based on the virtual instrument is proposed through combining the design concept of virtual instrument with the conventional ultrasonic testing method in currently. The detection system was introduced from three aspects: mechanical design, electrical control and ultrasonic testing instrument. The development cycle of the ultrasonic testing instrument is short with high efficiency. The software programming is flexible and can be improved when needed. It has laid the foundation for graphical display of pipe on-line automatic ultrasonic testing.
- Virtual instrument /
- Ultrasonic testing /
- Steel pipe

[1]	郑晖, 林树青.超声检测［M］.北京: 中国劳动社会保障出版社, 2008: 3-4.
[2]	邹明, 陈晓. 超声波检测技术研究进展［J］. 世界科技研究与发展, 2010,32(2): 198-199.
[3]	黄剑. 虚拟仪器技术及应用综述［J］. 计量与测试技术, 2010, 37(4): 42-43.
[4]	HARISH Ganapathy. Performing automated ultrasound testing of pipes［DB/OL］. http://sine.ni.com/cs/app/doc/
