基于USB AE模块的便携式管道声发射泄漏检测系统开发

基金项目:

成套装置承压设备预知检测及动态风险管理技术研究资助项目(2011BAK06B03)

详细信息

Development on Pipeline Leak Detection System Based on Portable USB Acoustic Emission

摘要: 基于USB AE模块的便携式声发射仪是一种新型的声发射检测设备。阐述了采用声发射方法检测管道泄漏的原理、USB声发射设备的结构和特性，分析了现有USB声发射检测系统存在的局限性。以Visual Studio C++作为程序开发平台，设计了针对管道泄漏这一特定环境和对象的便携式USB声发射检测系统。通过管道泄漏模拟试验，验证了系统设计方案的合理性，实现了声发射信号采集、数据处理和声发射源定位等功能。
- 声发射 /
- USB AE /
- 系统开发 /
- 管道泄漏检测
Abstract: Portable USB acoustic emission device is a new type of acoustic emission testing equipment. This paper describes the principles of using acoustic emission to detect pipeline leaks and the structure and characteristics of the USB AE, analyzes the limitations of the existing USB acoustic emission detection system. Based on the above-mentioned points, we have developed a Portable USB acoustic emission detection system for pipeline leak on Visual Studio C++ 2012 software platform. By pipeline leakage simulation experiments, we verify the system design is feasible. And the system can achieve the acoustic emission signal acquisition, data processing and acoustic source locating functions.
- Acoustic emission /
- USB AE /
- System development /
- Pipeline leak detection

[1]	ASTM E1316—1996Terminology for Nondestructive Examination［S］.
[2]	李培江,童官军.基于USB 的声发射信号高速采集系统的研究［J］.测控自动化,2011,27(2)：94-96.
[3]	童官军,王汝笠.多通道声发射高速数据采集系统的研制［J］.无损检测,2009,31(2):150-153.
[4]	孔德连.声发射技术在阀门泄漏在线监测方面的应用［D］.北京市：北京化工大学，2010.
[5]	Kaewwaewnoi W, Prateepasen A, Kaewtrakulpong A. Investigation of the relationship between internal fluid leakage through a valve and the acoustic emission generated from the leakage［J］. Measurement,2010(4):274-282.
[6]	MILLER R K, POLLOCK A A, WATS D J, et al. A reference standard for the development of acoustic emission pipeline leak detection techniques［J］. NDT&E,1999,32(1):1-8.
[7]	胡昌洋，杨钢锋，黄振峰，等.声发射技术及其在检测中的应用［J］.计量与测试技术,2008,35(6):1-4.
[8]	沈功田，刘时风，王玮.基于声波的管道泄漏点定位检测仪的开发［J］.无损检测,2010,32(1):53-56.
