钢轨踏面电磁超声检测信号处理方法

基金项目:

国防科技工业技术基础科研资助项目(B1220102302)

详细信息

Electromagnetic Acoustic Signal Processing Methods for Rail Surface Detection

摘要: 针对钢轨踏面电磁超声检测信号幅值小、信噪比低的问题，研究适用于电磁超声的数字信号处理方法，利用小波变换对信号进行消噪处理，通过希尔伯特变换提取信号包络，并对处理后的数据进行超声成像。采用LabWindows/CVI和Matlab混合编程的方式设计上位机数据分析软件。试验表明，该方法显著提高了电磁超声回波信号的信噪比，能有效地检测钢轨踏面缺陷并进行定位。
- 电磁超声 /
- 小波变换 /
- 希尔伯特变换 /
- 超声成像
Abstract: To increase the amplitude and the SNR(Signal Noise Ratio) of electromagnetic acoustic signals in rail surface detection, proper signal processing methods were studied. Wavelet transform was used to denoise the signals and the signal envelopes were extracted through Hilbert transform algorithm. The ultrasonic images of the rail surface were presented, making the detection results more clearly. A hybrid programming language between LabWindows/CVI and Matlab was used to develop the software. Experiments indicated that the methods could improve the SNR of electromagnetic acoustic signals significantly, thus leading to the effective detection and location of rail surface defects.
- Electromagnetic acoustic /
- Wavelet transform /
- Hilbert transform /
- Ultrasonic image

[1]	Edwards R, Dixon S, Jian X. Characterisation of defects in the railhead using ultrasonic surface waves［J］. NDT&E International,2006(39):468-475.
[2]	Chahbaz A. Development of a Mobile Inspection System for Rail Integrity Assessment［R］. Transportation Development Centre Safety and Security Transport Canada,2000(6):3-10.
[3]	Vitaly I, Alexander V. Development of instruments for NDT of rail-tracks with use of contactless electromagnetic acoustic emission transducers(EMATs)［C］. 17th World Conference on Nondestructive Testing, Shanghai: Chsndt,2008:255-262.
[4]	Kang Lei, Mi Wujun, Lu Chao, el al. Research on weak signal detection technique for electromagnetic ultrasonic inspection system［C］. The 3rd IEEE Conference on Industrial Electronics and Applications, Singapore, 2008: Inst of Elec and Elec Eng Computer Society,2008.
[5]	张晓颖，马书林.数字包络的实现［J］.长春理工大学学报(自然科学版),2008,31(2):118-120.
