红外热像技术在混凝土检测中的应用现状和发展趋势

蒋济同, 范晓义

蒋济同, 范晓义. 红外热像技术在混凝土检测中的应用现状和发展趋势[J]. 无损检测, 2011, 33(2): 52-55.
引用本文: 蒋济同, 范晓义. 红外热像技术在混凝土检测中的应用现状和发展趋势[J]. 无损检测, 2011, 33(2): 52-55.
JIANG Ji-Tong, FAN Xiao-Yi. Application and Development of Infrared Thermal Image Technology on the Concrete Detection[J]. Nondestructive Testing, 2011, 33(2): 52-55.
Citation: JIANG Ji-Tong, FAN Xiao-Yi. Application and Development of Infrared Thermal Image Technology on the Concrete Detection[J]. Nondestructive Testing, 2011, 33(2): 52-55.

红外热像技术在混凝土检测中的应用现状和发展趋势

详细信息
    作者简介:

    蒋济同(1966-),男,中国海洋大学工程学院土木系系主任,教授,博士,主要从事建筑物无损检测和结构工程等研究工作。

  • 中图分类号: TG115.28

Application and Development of Infrared Thermal Image Technology on the Concrete Detection

  • 摘要: 分析和总结了国内外红外热像技术在混凝土检测领域中如何获取和改进外加热源,缺陷深度、大小的定量计算以及研究成果如何在复杂的实际工程当中运用的研究进展,指出了目前研究存在的局限性和不足,展望了红外热像技术在混凝土检测领域中的应用前景和发展方向。
    Abstract: Combined with the research development at home and abroad, following problems were analyzed and summarized in the paper, such as the application of infrared thermal image technology(ITIT) on the concrete detection, the quantitative calculation of depth and size of building defects, and the practical use of the research results in omplex projects. Limitations and deficiency of the current research were pointed out in the paper. The application prospect and development direction of ITIT in the concrete detection field were also indicated.
  • [1] 张荣成.红外热像法检测建筑物外墙饰面施工质量的试验研究[J].建筑科学,2002,18(1):40-44.
    [2] 周书铨.红外辐射测量基础[M].上海:上海交通大学出版社,1991:7-10
    [3] 李为杜.红外检测技术基本原理及应用[J].施工技术,1998(11):34.
    [4] Wiggenhauser H. Active IR-applications in civil engineering[J]. Infrared Physics & Technology,2002,43(3-5):233-238.
    [5] Maierhofer Ch, Brink A, Rollig M, et al. Transient thermography of structural investigation of concrete and composites in the near surface region[J]. Infrared Physics & technology,2002,43(3-5):271-278.
    [6] Takahide Sakagami, Shiro Kubo. Development of a new non-destructive testing technique for qualitative evaluations of delamination defects in concrete structure based on phase Delay measurement using lock-in thermography[J]. Infrared Physiec & Technology,2002,43(3-5):311-316.
    [7] Takahide Sakagami, Shiro Kubo. Applications of pulse heating thermography and lock-in thermography to quantitative nondestructive evaluations[J]. Infrared Physics & Technology,2002,43(3-5):211-218.
    [8] Vallerand S, Maldague X. Defect characterization in pulsed thermography: a statistical method compared with Kohonen and Perceptron neural networks[J]. NDT&E International,2000,33(5):307-315.
    [9] 宋显辉,王建军,李卓球.碳纤维混凝土局部损伤检测的实验研究[J].武汉理工大学学报,2004,26(3):44.
    [10] 黄莉,龙曦,李卓球.碳纤维混凝土电热红外无损检测的灵敏性分析[J].武汉理工大学学报,2005,27(3):37-40.
    [11] 黄莉,李卓球,宋显辉.碳纤维增强混凝土中裂纹的红外热线和检测方法与机理研究[J].实验力学,2003,18(3):403-408.
    [12] Pietro Giovanni Bocca, Paola Antonaci. Experimental study for the evaluation of creep in concrete through thermal measurements[J]. Cement and Concrete Research,2005,35(9):1776-1783.
    [13] Defer D, Shen J, Lassue S, et al. Non-destructive testing of a building wall by studying natural thermal signals[J]. Energy and Buildings,2002,34(1):63.
    [14] 王永茂,郭兴旺,李日华,等.缺陷大小和深度的红外检测[J].无损检测,2003,25(9):458-461.
    [15] 杨锐玲.红外热成像法探测混凝土缺陷的实验及理论研究[D].武汉:武汉大学,2004:3-6.
    [16] 王婷,赵鸣,李杰.红外CT模拟在混凝土板内部缺陷探测中的应用[J].计算力学报,2007,24(5):579-584.
    [17] 王婷,赵鸣,李杰.识别混凝土板内部缺陷的人工神经网络算法[J].同济大学学报,2007,35(3):304-308.
    [18] 孙格靓,王厚亮,李建保.碳纤维混凝土构件破坏过程的动态混凝土检测[J].碳素技术,2004(4):25-31.
    [19] Clark M R. Application of infrared thermography to the non-destructive testing of concrete and masonry bridges[J]. NDT&E International,2003,36(4):265-275.
    [20] Clark M R, Mc Cann D M, Forde M C. Infrared thermographic investigation of railway track ballast[J]. NDT&E International,2002,35(2):83-94.
    [21] Clark M R, Forde M C. Infrared Thermography Assessment of Masonry Arch Bridges Laboratory and Field Case Studies[C]. Germany: International Symposium(NDT-CE 2003).
    [22] Valluzzi M R, Bondì A. Structural investigations and analyses for the conservation of the Arsenal of Venice[J]. Journal of Cultural Heritage,2002,3(1):65.
    [23] Maierhofer Ch, Brink A, Rllig M, et al. Detection of shallow voids in concrete structures with impulse thermography and radar[J]. NDT&E International,2003,36(4):257-263.
    [24] 邓明德,樊正芳耿,乃光,等.混凝土的微波辐射和红外辐射随应力变化的实验研究[J].岩石力学与工程学报,1997,16(6):577-583.
    [25] 邓明德,钱家栋,尹京苑,等.红外遥感用于大型混凝土工程稳定性监测和失稳预测研究[J].岩石力学与工程学报,2001,20(2):147-150.
    [26] 刘善军,张艳博,吴立新,等.混凝土破裂与渗水过程的红外辐射特征[J].岩石力学与工程学报,2009,28(1):53-58.
    [27] 杜红秀,张雄,韩继红.混凝土火灾损伤的红外热像检测与评估[J].同济大学学报,2002,30(9):1078-1082.
    [28] 杜红秀,张雄,韩继红.混凝土构筑物的火灾危害与损伤检测评估[J].建筑材料学报,1998,1(2):175-181.
    [29] 杜红秀,张雄,韩继红,等.混凝土火烧损伤的红外热像检测与分析[J].建筑材料学报,1998,1(3):223-226.
    [30] 张洁龙,杜红秀,张雄.火灾损伤混凝土结构红外热像检测与评估[J].高技术通讯,2002,02:62-65.
    [31] 杜红秀,张雄.钢筋混凝土结构火灾损伤的红外热像-电化学综合检测技术与应用[J].土木工程学报,2004,37(7):41-46.
    [32] 张维.建筑物红外检测技术[J].无损检测,1997,19(5):130-131.
