CNG储气井超声波自动检测系统初探

详细信息

Automatic Ultrasonic Testing Experimental System for CNG Gas Storage Wells

摘要: 针对现有CNG储气井井壁因腐蚀导致泄露、爆裂等问题, 提出了一套超声波自动检测系统, 包括超声信号的采集、腐蚀情况分析、显示、存储和回放。系统硬件包括超声波发射/接收卡和探头定位装置, 软件使用VC++2005作为平台研发, 并采用Microsoft SQL Server 2000存储数据。在实验中对一段井壁进行了测量, 效果较好。
- 超声波 /
- CNG /
- 储气井 /
- 探伤系统 /
- 在线检测
Abstract: To detect the corrosion of CNG storage wells, we proposed a system for automatic ultrasonic test, which included collection of ultrasonic signal, analysis of corrosive data, display, storage and recognition. The hardware system included an ultrasonic transmitter and receiver card and an ultrasonic probe jig. The software was written in VC++, and Microsoft SQL Server 2000 was used for database. Our experiment showed that the system could effectively detect the defects in the sidewall of CNG storage wells.
- Ultrasonic /
- CNG /
- Gas storage well /
- Testing system /
- On-line testing

[1]	刘清友, 何霞, 孟少辉.CNG地下储气井安全性分析[J].天然气工业, 2005, 25(1): 138-140.
[2]	Grimes Keith. Changing Role of Inspection[J]. Proceedings of the 1998 International Pipeline Conference, 1998, 2(1): 379-387.
[3]	Kobayashi Motoi. NKK Ultrasonic Pipeline Inspection Pig[J]. NKK Technical Review, 1999(80): 46-50.
[4]	周佳琪. 海底管道超声检测数据采集模块的设计与实现[D].上海: 上海交通大学, 2007.
[5]	关保清, 苏真伟.大型回转轴超声波自动探伤系统[J].仪表技术与传感器, 2008, 1(1): 88-90.
[6]	赵秀粉, 殷国富.基于大型回转工件的超声波在线自动检测系统[J].四川大学学报, 2008, 40(3): 173-177.
[7]	GB 9254—1998 信息技术设备的无线电骚抗限值和测量方法[S].
[8]	GB/T 17618 信息技术设备抗扰度限值和测量方法[S].
[9]	左林, 田建新.基于PCI总线的高性能多通道超声波发射/接收卡[J].无损检测, 2003, 25(4): 198-200.
[10]	史亦韦.超声检测[M].北京: 机械工业出版社, 2005: 92-97.
[11]	张志永.水浸聚焦超声波探伤原理[M].北京: 国防工业出版社, 1985: 15-89.
[12]	飞思科技产品研发中心.小波分析理论与MATLAB7实现[M].北京: 电子工业出版社, 2005.
