锅炉水冷壁管沉积物下腐蚀损伤特征及其超声检测

龙会国, 邓宏平, 何朋飞, 杨湘伟

龙会国, 邓宏平, 何朋飞, 杨湘伟. 锅炉水冷壁管沉积物下腐蚀损伤特征及其超声检测[J]. 无损检测, 2014, 36(6): 19-23.
引用本文: 龙会国, 邓宏平, 何朋飞, 杨湘伟. 锅炉水冷壁管沉积物下腐蚀损伤特征及其超声检测[J]. 无损检测, 2014, 36(6): 19-23.
LONG Hui-guo, DENG Hong-ping, HE Peng-fei, YANG Xiang-wei. Characteristics of Corrosion Damage under the Deposition in a Boiler Water-cooled Wall Tubes and its Ultrasonic Testing Technique[J]. Nondestructive Testing, 2014, 36(6): 19-23.
Citation: LONG Hui-guo, DENG Hong-ping, HE Peng-fei, YANG Xiang-wei. Characteristics of Corrosion Damage under the Deposition in a Boiler Water-cooled Wall Tubes and its Ultrasonic Testing Technique[J]. Nondestructive Testing, 2014, 36(6): 19-23.

锅炉水冷壁管沉积物下腐蚀损伤特征及其超声检测

详细信息
  • 中图分类号: TG115.28,TB302.5

Characteristics of Corrosion Damage under the Deposition in a Boiler Water-cooled Wall Tubes and its Ultrasonic Testing Technique

  • 摘要: 通过金相、扫描电镜、超声波检测等试验,对某锅炉20 G钢水冷壁管内壁介质沉积物下腐蚀损伤特征及其超声技术进行分析。结果表明:水冷壁管内壁沉积物下腐蚀产物氢元素与钢中渗碳体反应,造成内部组织脱碳、空隙,沿晶产生裂纹并扩展,材料力学性能降低。横波超声检测对水冷壁氢腐蚀裂纹比较敏感,5 MHz、K1及小晶片尺寸的横波探头能对材质损伤裂纹进行可靠检测,根据超声检测波形特征及缺陷回波波幅当量值,能很好地反映其氢腐蚀及裂纹扩展程度。
    Abstract: The steam-side corrosion damage characterization and ultrasonic testing technique of the internal surface of water-cooled wall tube made of 20G steel removed from boiler of some power plant had been investigated by metallurgic inspection, scanning electron microscope-energy dispersive and other tests. The examination results showed that the reaction process of hydrogen and cementite in grain boundary caused decarburization of water-cooled wall tube, void fraction and grain boundary cracks initiation and propagation, and mechanical performance degradation. Due to the fact that the ultrasonic transverse wave is sensitive to the hydrogen corrosion cracks, small chip size of transverse wave probe of K1, 5MHz frequency is used to test the corrosion grain boundary cracks, showing high reliability. The wave form characteristics of the echo by hydrogen corrosion cracks in the samples and its equivalent amplitude can be used to assess the degree of hydrogen corrosion cracks.
  • [1] 徐洪. 高压锅炉水冷壁管碱腐蚀诊断与机理研究[J]. 中国电机工程学报, 2003,23(2):183-187.
    [2] DOOLEY R B, PATERSON S. Proceedings of the 55th international water conference[C].//Pittsburgh,PA. 1994.
    [3] 侯祥松,史翊翔,杨景标. T91煤粉锅炉水冷壁结垢腐蚀情况及其原因分析[J]. 电站系统工程,2007,23(2):26-28.
    [4] 李家伟,陈积懋.无损检测手册[M].北京:机械工业出版社,2002.
    [5] 李大东.加氢处理工艺与工程[M]. 北京:中国石化出版社,2004.
    [6] 李晓刚,陈华,谢根栓,等. 20G钢氢腐蚀的超声背散射检测[J]. 腐蚀科学与防护技术,1994,6(2):179-183.
    [7] 龙会国, 龙毅, 陈红冬, 等.铝母线焊缝超声波检测工艺参数的选择[J]. 无损检测,2013(2):41-47.
    [8] 龙会国,邓宏平. 电站锅炉小径管焊缝超声波检测技术[J]. 锅炉技术. 2012,43(4):59-62.
计量
  • 文章访问数:  3
  • HTML全文浏览量:  0
  • PDF下载量:  3
  • 被引次数: 0
出版历程
  • 收稿日期:  2013-08-12
  • 刊出日期:  2014-06-09
