φ500~1000mm管材超声波水浸法自动探伤设备

详细信息

Automated Ultrasonic Water-Immersion Testing System for φ500-1000mm Pipe

摘要: 大直径管材水浸法超声波自动化探伤设备由探伤主机、辊道机械传动系统、电气控制系统、水路系统、超声波探伤仪及计算机系统组成。所研制设备采用水浸法，通过产生横波进行全面扫查, 然后由超声波探伤仪判别, 最后由计算机记录缺陷大小并报警, 最终实现超声波自动化探伤要求。
- 大径管 /
- 超声波局部水浸法探伤 /
- 水程法 /
- 组合探头 /
- 自动超声波探伤
Abstract: Automated water-immersion ultrasonic detection equipment for large-diameter pipe is consist of testing host, roller mechanical transmission system, electric control system, water system, ultrasonic flaw detector and computer system. By using water-immersion way and by generating S-waves for fully scanning, the equipment can be used to identify and then discriminate flaws by the ultrasonic flaw detector, and finally the computer can record the defect size and alarm. Thus it is able to meet the requirements of ultrasonic automated testing.
- Large-diameter pipe /
- Ultrasonic partial immersion testing /
- Water path method /
- Combination probe /
- Automated ultrasonic testing
