The Application of the Acoustic Emission in the Online Detection of Fine Blanking Mold Chipping
-
摘要: 经过对精冲企业的详细调研发现，在精冲过程中模具冲头主要失效形式为断裂和崩刃，其中模具冲头崩刃难以检测，造成成品率下降并且阻碍了高速精冲生产线的全自动化。通过多次试验，探索性地提出利用声发射信号检测技术在精冲模具生产线上实施在线检测的方法。介绍了声发射信号产生的基本原理、常见的分析方法以及模具冲头崩刃的发生机理，深入分析了金属板材冲压过程的声发信号。通过识别冲压过程中的声发射信号，探究了基于声发射系统在模具崩刃在线检测中的可行性。Abstract: Tremendous researches on the fine molding process in certain enterprises indicate that mold chipping is one of the most common forms of mold failures and this kind of mold failure is especially difficult to detect which will result in yield decline and hindering fully automated process in high-speed production line. Here we explored the applicability of the acoustic emission based detection technology in fine mold production line. The basic theories of the generation of acoustic emission in sheet metal were introduced and the method of how to analyze the signal and the mold chipping mechanism was presented. Finally, an in-depth analysis of acoustic emission in the metal sheet stamping process was proposed, trying to validate the feasibility of the acoustic emission based detecting technology in the online mold chipping.
-
Keywords:
- Mold chipping /
- Acoustic emission detection /
- Signal analysis
-
-
[1] 梅瑛，黄大宇，弓金霞.冷挤压冲头的损坏形式研究［J］.金属成型工艺,1997(1):31-33. [2] 张志刚，阙沛文，雷华明，等.Lamb波与SH板波双模式电磁超声检测系统的设计与实验［A］.工业仪表与自动化装置,2005(3):22-24. [3] 沈功田，耿荣生，刘时风，等.声发射信号的参数分析法［J］.无损检测,2002(2):72-77. [4] 张守茁，席镇，杨殿魁，等.基于声发射技术的金属动态塑性摩擦研究［J］.润滑与密封,2006(11):109-114. [5] 姚晓山，张永祥，明延涛.基于经验模态分解的齿轮裂纹声发射检测［J］.无损检测,2009(6):464-467. [6] 卢文祥，杜润生.工程测试与信息处理(第二版)［M］.武汉：华中科技大学出版社,2008. [7] 秦国栋，刘志明，王文静.16Mn钢疲劳过程中的声发射特性研究［J］.中国安全科学学报,2005(8):105-108. [8] 耿荣生，景鹏，付刚强.声发射波形分析技术在复合材料故障评价中的作用［J］.无损检测,1999(7):289. [9] Stefanie E. Stanzl-Tschegg, Louise Filion, et al. Strength properties and density of SO2 polluted spruce wood［J］. Holz als Roh - und Werkstoff,1999,57(2):121-128. [10] Reiterer A, Stanzl-Tschegg S E, Tschegg E K. Mode I fracture and acoustic emission of softwood and hardwood［J］. Wood Science and Technology,2000,34(5):417-430.
