Multiple-View Ultrasonic Imaging Technique for Pipe Welds
-
摘要: 通过超声C扫描和三视投影成像技术对管道焊缝缺陷进行定性定量评估和诊断分析。研究与应用结果表明，采用超声自动扫描多维投影成像方法可以直观地得到焊缝区缺陷的位置、大小、分布和取向等特征信息，使缺陷识别的准确性和检测可靠性明显提高。该项技术已在电力等工业部门管道焊缝的无损检测中得到应用。Abstract: A new nondestructive testing and evaluation (NDT&E) technique by using multiple-view ultrasonic imaging based on mobile automated scanning system for pipe welds in-service was described. Ultrasonic C-scan and three-dimensional P-scan were established to evaluation and diagnosis of defects in pipe welds. The results presented showed that the characteristics of defect in weld, for examples, location, distribution and orientation and size of defects and so on, were be exhibited well by employing the approach. It offered an effective instrument for improving NDT&E detectable probability and reliability of finding defects. The developed multiple-view ultrasonic imaging technique had been applicated in NDT&E of pipe welds in steam power industry so far.
-
Keywords:
- Ultrasonic multiple-view imaging /
- Defect evaluation /
- Pipe welds
-
-
[1] Baldev Raj C V, Jayakumar Subramanian T. Non-destructive test of welds[M]. Alpha Science International Ltd,2000. [2] Raad de J A, Dijkstra F H. Mechanized ultrasonic testing on girth welds during pipeline construction[J]. Materials Evaluation,1997,55(7):890-895. [3] Ditchburn R J, Burke S K, Scala C M. NDT of welds: state of the art[J]. NDT&E International,1999,29(2):111-117. [4] Baldev Raj, Subramanian C V. Nondestructive testing of welds[J]. Materials Evaluation,1999,57(12):1251-1254. [5] Stuart Kleven. Ultrasonic inspection of explosion welded titanium clad plate[J]. Materials Evaluation,1996,54(5):557-560. [6] Subramanian C V, Thavasimuthu M, Rajagopalan C, et al. Ultrasonic test procedure for evaluating fuel clad endcap weld joints of PHWRs[J]. Materials Evaluation,1995,53(11):1290-1295. [7] 刘松平，陈积懋，郭恩明.先进的超声手动扫描成像检测技术[J].无损检测,1997,19(6):151-153.
