The Real-time Imaging Detection Technology of Brazing Metal Honeycomb
-
摘要: 介绍了金属蜂窝钎焊件生产制造过程中的实时成像检测。传统射线照相技术受限于管径及射线束角度，透照有效区域小，大型蜂窝结构件检测效率低；同时还会发生由于工件厚度变化致使芯格影像变形的问题，影响检测结果的判断。运用实时成像技术对蜂窝结构件移动扫描检测，有效地解决了上述问题，同时使用分辨率测试卡，保障了系统的分辨力，获得了满意结果。Abstract: This paper introduces the real-time imaging detection technology during the manufacturing process of brazing metal honeycomb. Traditional radiography is limited by the diameter-ray beam angle and the effective areas of Tran-illumination are small, hence the detection of large-scale honeycomb structure are less efficient; Meanwhile, the imaging deformation of the core grid due to the thickness change of the work piece might occur. The paper uses the real-time imaging technology to dynamically scan the honeycomb structure and to detect defects, and it is proven effective to solve the above problems. At the same time, a satisfactory result was obtained based on the system resolution provided by the resolution test meter.
-
Keywords:
- Honeycomb structure /
- Core grid image /
- Real-time imaging technology /
- Test meter
-
-
[1] 张咏红，张为民.典型复合材料损伤—损伤实时成像检测图谱的解释［J］.机械工程与自动化,2009,152(1):109-111. [2] 张咏红，张为民.复合材料X射线实时成像检测关键参数分析［J］.现代机械,2008(5):81-84. [3] 美国无损检测学会编.美国无损检测手册·射线卷［M］.美国无损检测手册译审委员会译.上海：世界图书出版公司,1992. [4] 郑世才.射线检测(国防科技工业无损检测人员资格鉴定与认证培训教材)［M］.北京：机械工业出版社,2004,06. [5] 刘松平，陈积懋.大密度金属钎焊蜂窝构件超声检测与缺陷识别技术的研究［J］.无损检测,1995,17(10):271-273. [6] 石剑，吕健.金属蜂窝真空钎焊件的超声波检测［J］.无损检测,2007,29(7):392-395. [7] 刚铁，李伟力.扩散焊接头质量检测的研究现状［J］.焊接,2000(5):6-10.
