空心叶片残留型芯影像的射线照相对比度

详细信息

The Radiographic Image Contrast of Residual Ceramic Cores in Hollow Blades

摘要: 从型芯影像射线照相对比度的角度分析了残芯在叶片中的可检性。通过推导的残芯影像对比度公式, 分析了影像对比度的各种影响因素, 并在理论上进行了计算。从试验与理论计算相比较的结果表明, 通过改善梯度和散射能有效地提高型芯影像的对比度。得出型芯在叶片材料上的最小可检厚度。
- 空心叶片 /
- 残留型芯 /
- 射线检测 /
- 影像对比度 /
- 散射比
Abstract: The paper aimed to evaluate whether the residual ceramic core in a hollow blade could be found through analyzing the residual ceramic cores image of radiographic contrast. Moreover, it analyzed some important influence factors of imaging contrast which could be educed from the formula of images radiographic contrast. Forthermore, some values under certain energy were also calculated through the formula. In addition, through comparing the results of experiment with the calculating results according to the formula, it was shown that the image contrast could be increased efficiently by improving the grads of film and the scattering ratio of X-ray. Finally, the minimum ceramic cores thickness which could be tested on the material of blades was also acquired.
- Hollow blade /
- Residual ceramic core /
- Radiographic testing /
- Image contrast /
- Scattering ratio

[1]	陈荣章.航空铸造涡轮叶片合金和工艺发展的回顾与展望[J].航空制造技术, 2002, (2): 19-23.
[2]	张立同, 曹腊梅, 刘国利, 等.近净形熔模精密铸造理论与实践[M].北京: 国防工业出版社, 2007.
[3]	国防科技工业无损检测人员资格鉴定与认证培训教材编审委员会.射线检测[M].北京: 机械工业出版社, 2004.
[4]	美国无损检测学会.美国无损检测手册·射线卷[M].上海: 世界图书出版公司, 1992.
[5]	兑卫真, 杨晓华.金属材料X射线散射比的测定[J].热处理, 2001, (2), 29-31.
[6]	日本无损检测协会, 编.射线探伤B[M].李衍, 译.北京: 机械工业出版社, 1988.
