锁相红外检测中相位检测方法

基金项目:

黑龙江省重点攻关资助项目(GB06A512)

详细信息

Study of Phase Detection in Lockin Thermography Nondestructive Testing

摘要: 介绍了调制加热阶段的一维热波导热方程。为了减少图像序列采集数量，针对相位法红外热成像检测提出了获取热波信号相位信息的方法，即相关检测算法。利用噪声信号与参考信号不相关的原理，有效地提取微弱被测信号。通过对同一组图像序列的处理，将其与4点平均算法比较，证实该算法采集信息少，具有较高检测精度。同时也验证了相位信息对样品表面非均匀性不敏感，使得相位法红外热像技术在无损检测中有广泛应用。
- 红外热成像检测 /
- 锁相 /
- 相关算法 /
- 相位检测
Abstract: Onedimensional heat conduction equation of thermal wave during modulated heating was described. A method, correlation algorithm, was promoted to detect phase information in lockin thermography nondestructive testing in order to reduce sample images. Using the principle of the reference signal being uncorrelated to the measured signal, the latter could be extracted easily. Compared with averaging fourpoint algorithm, correlation algorithm was shown to have better precision and need less information. The experiment also confirmed that the phase was less affected by surface nonuniformity. So the phase thermography technique was expected to have wide applications in NDT field.
- Infrared imaging testing /
- Lockin /
- Correlation algorithm /
- Phase detection

[1]	王迅,金万平,张存林,等.红外热波无损检测技术及其发展[J].无损检测,2004,26(10):497-501.
[2]	Meola C, Carlomagno G M. Recent advances in the use of infrared thermography[J]. Measurement Science and Technology,2004,(15):27-58.
[3]	Wu D, Salerno A, Schbnbach B, et al. Phasesensitive modulation thermography and its applications for NDE[J]. Proc SPIE,1997,(3056):176-183.
[4]	张建合,郭广平.国内外飞速发展的热像无损检测技术[J].无损探伤,2005,29(1):1-4.
[5]	Takahide Sakagami, Shiro Kubo, Yasuhiro Teshima. Fatigue crack identification using neartip singular temperature field measured by lockin thermography[J]. Proc SPIE,2000,4020:37-46.
[6]	Datong Wu, Antonio Salerno, Bernd Schnbach, et al. Phase sensitive modulation thermography and its applications for NDE[J]. SPIE,1997,3056:176-183.
[7]	Weimin Bai, Brian S Wong. Nondestructive evaluation of aircraft structure using lockin thermography[J]. Proc SPIE,2000,3994:37-46.
[8]	刘波,李艳红,张小川,等.锁相红外热成像技术在无损检测领域的应用[J].无损探伤,2006,30(3):12-15.
[9]	白奉天,罗飞路,张玉华.软正交矢量型LIA在微弱信号检测中的应用[J].现代电子技术,2003,(9):18-20.
[10]	薛书文,宗明成,丁铁英,等.利用红外热成像技术检测金属内部近表缺陷[J].红外与毫米波学报,1998,17(6):424-428.
