全系列型号钢管焊缝X射线成像检测系统

X-Ray Real-Time Imaging Inspection System of All Series and Various Type Steel-Tube Weld

摘要: 介绍了一种能够完成对各种不同规格型号全系列钢管焊缝进行X射线成像的检测系统。针对不同管径、长度和壁厚的钢管，分别介绍了与其相适应的检测方法。该系统具有结构功能多、移动定位精度高、智能性高、适用性强及高效率等优点。

Abstract: X-ray real-time imaging inspection system for all series and various type steel-tube welds was introduced. To various diameter, length and thickness, the adaptive inspection methods were introduced. This system had the benefits of more function, the high precision for orientation, the high extent, high feasibility and the high efficiency.
