Selection of Radial and Axial Components from Magnetic Flux Leakage Signals
-
摘要: 缺陷漏磁场的径向分量和轴向分量是漏磁检测中经常检测的物理量, 两者之间如何选择, 至今尚无定论。采用等效面偶极子模型分析了缺陷漏磁场的空间分布特点, 解释了径向分量比轴向分量衰减更快的原因。结合有限元方法, 研究了不同深度、宽度的二维矩形槽和不同倾角的梯形槽缺陷的漏磁场分布, 分析了径向分量与轴向分量的变化特点, 总结了缺陷参数变化时临界点的变化趋势。从探头设计的角度, 考察了探头提离值以及缺陷参数对缺陷漏磁场信号轴向和径向分量幅值的影响, 提出利用临界点作为检测分量的选取原则。Abstract: Both radial component and axial component are the favorite testing factors in the magnetic flux leakage testing(MFLT). Equivalent magnetic dipole model was taken to analyze the distribution feature of magnetic flux leakage of defects, demonstrating the fact that radial component decays more rapidly than axial component. The flux leakage due to steel pipe defects with various defect depth(10% to 40%) and width(0.5 mm to 20 mm) was calculated using finite element method. The sharpness angle of the notch was also taken into consideration in the calculation. The critical point, where the amplitude of radial component is equal to that of axial component, transits with various parameters of defects. The tendency of shift of critical point is discussed for the different cases. The effects of lift-off of sensor and defect parameters on amplitude of components of flux leakage were studied from sensor design. The conclusion is drawn that critical point can be used to determine which component would be pick out by one dimensional sensor in designing MFLT equipments.
-
Keywords:
- Magnetic flux leakage testing /
- Axial component /
- Radial component /
- Critical point
-
-
[1] Lord W. Application of numerical field modeling to electromagnetic methods of nondestructive testing[J]. IEEE Trans on mag, 1983, 19(6): 2437-2442. [2] Edens W C. Electromagnetic inspection: wall loss and flaw location in oil country tubular goods[J]. Materials Evaluation, 1992, 50(4): 476-490. [3] Moore D P, Bayars H G. Economics important in selecting monitoring techniques[J]. Oil and Gas Journal, 1990, 88(32): 68-73. [4] Huang Zuoying, Que Peiwen, Chen Liang. 3D FEM analysis in magnetic flux leakage method[J]. NDT&E International, 2006, 39(1): 61-66. [5] 李路名, 郑鹏, 黄松岭, 等.表面裂纹宽度对漏磁场Y分量的影响[J].清华大学学报(自然科学版), 1999, 39(2): 43-45. [6] 汪友生, 潘孟贤, 何辅云.缺陷参数与漏磁信号相互关系的实验研究[J]. 合肥工业大学学报(自然科学版), 1998, 21(5): 28-31. [7] 王太勇, 蒋奇.管道缺陷定量识别技术的研究[J]．天津大学学报, 2003, 36(1), 45-48. [8] 杨涛, 王太勇, 李清, 等.油气管道缺陷漏磁检测试验[J]. 天津大学学报, 2004, 37(8): 686-689. [9] Mukhopadhyay S, Srivastava G P. Characterisstion of metal loss defects from magnetic flux leakage signals with discrete wavelet transform[J]. NDT&E International, 2000, 33(1): 57-65. [10] 蒋奇, 王太勇.钢管缺陷漏磁场及影响漏磁信号因素的分析[J].钢铁研究, 2002, 128(5): 20-24. [11] 汪友生, 徐小平, 沈兰荪.铁磁材料的漏磁检测[J]. 电子测量与仪器学报, 2000, 14(3): 45-49. [12] 杜志叶, 阮江军, 余世峰, 等.Hilbert变换在钢管漏磁检测缺陷定量化识别中的应用研究[J]. 电工技术学报, 2007, 22(1): 17-21, 28. [13] 杜志叶, 阮江军, 余世峰, 等.油管漏磁检测的有限元建模技术研究[J].中国电机工程学报, 2007, 27(27): 108-113. [14] 黄松岭.管道磁化的有限元优化设计[J].清华大学学报, 1998, 40(2): 67-69. [15] 杜志叶, 阮江军, 王贤琴, 等.基于Ansoft软件的钢管漏磁检测3D有限元仿真研究[J].无损检测, 2005, 27(6): 281-285.
