厚壁压力容器TOFD检测技术参数

基金项目:

南昌航空大学研究生创新基金资助项目(YC2012003)

详细信息

The Parameters of TOFD Detection of Thick-walled Pressure Vessel

摘要: 基于超声波衍射时差法(TOFD)检测原理和技术特点，在分析厚壁容器TOFD检测存在盲区的基础上，针对性提出采用分层检测以减小检测盲区的方法，结合理论计算和试块试验测试结果，提出和优化分层检测参数。根据参数优化的结果，指导厚度150 mm厚壁焊缝的检测。检测结果表明，超标缺陷检出率高，缺陷性质判断准确，缺陷尺寸测量精度高；该分层检测参数设计方法可以推广应用于相关的厚壁容器检测。
- TOFD /
- 厚壁工件 /
- 表面盲区 /
- 检测技术
Abstract: Based on TOFD technique detection principle and technical characteristics, and on the analysis of dead zones existing in thick-walled vessel TOFD inspection, this article proposed layered detection methods to reduce the dead zone of inspection. Combined with the theoretical calculations and experimental test results of test block, tiered testing parameters were proposed and optimized. Detection of 150 mm thick weld was guided according to the results of parameter optimization, and test results showed that excessive defect detection rate could be obtained and the nature of defects could be more accurately determined with high accuracy of defect size. So the layered detection parameters design method can be applied to the thick-walled vessel associated testing.
- TOFD /
- Thick-walled test block /
- Dead zone in face /
- Detection technology

[1]	林立华.压力容器无损检测技术［J］.机械,2007(34):1-3.
[2]	刘松平，刘菲菲，李乐刚，等.铝合金搅拌摩擦焊缝的无损检测方法［J］. 航空造技术,2006(3):81-84.
[3]	刘松平，刘菲菲，李乐刚，等.搅拌摩擦焊缝变入射角超声检测方法研究［J］. 无损检测,2006,28(5):225-228.
[4]	倪进飞.TOFD检测技术基本原理及其应用探讨［J］.广东电力,2007(10):17-19.
[5]	袁涛，曹怀祥，祝卫国，等.TOFD超声成像检测技术在压力容器检验中的应用［J］.压力容器,2008(2):58-60.
[6]	郭小联.厚壁压力容器声源定位理论分析与试验研究［C］//第11届中国声发射学术研讨会.杭州：［出版者不详］,2006.
