双金属转子复合层超声特征成像系统

详细信息

Ultrasonic Feature Imaging System for Testing Bimetal Rotor Clad Layer

摘要: 利用超声特征扫描成像技术，研制了一套检测双金属转子复合层分层缺陷的设备，实现对双金属转子9个柱塞孔的自动检测。检测结果保存在工控机中，后处理时可以按相位(深度) 特征成像，也可按当量分布特征成像，能准确地将分层缺陷找到，并判断其大小。系统完成后，对实际的样品进行了成像实验，能够得到分层缺陷的各种特征信息，系统稳定性和可重复性高。
- 超声波检测 /
- 特征扫描 /
- 分层缺陷 /
- 柱塞孔
Abstract: An ultrasonic feature scan imaging system used for testing delamination flaw probably existing in the bimetal rotor clad layer was studied and developed. The bimetal rotor with nine column holes could be tested automatically. All the wave train of testing result would be saved in computer for post processing. Various imaging modes, including depth imaging and amplitude imaging, could be used to find delamination flaws accurately and to estimate their size. Imaging experiments for actual work piece was done using the system, and all kinds of feature information were collected. The system was characteristic of high stability and good repeat ability.
- Ultrasonic testing /
- Feature scan /
- Delamination flaw /
- Column holes

[1]	丁学龙.双金属转子复合层超声波检测[J].国外金属热处理,2000,(10):53.
[2]	Chern E James. Concept of non-destructive evaluation[J]. Materials Evaluation,1991,49(9):1228-1235.
[3]	李家伟，陈积懋.无损检测手册[M].北京：机械工业出版社,2002:218-223.
[4]	林书玉.超声换能器的原理及设计[M].北京：科学出版社,2004:73-90.
[5]	张锐.复合材料手动扫描超声特征成像检测系统的研制[J].材料工程,2003,(4):240.
