磁致伸缩导波技术检测管道缺陷

详细信息

Application of Magnetostrictive Ultrasonic Guided Wave Technique for the Inspection of Defects in Pipes

摘要: 介绍了磁致伸缩T模态导波技术检测管道缺陷的原理。应用MsSR3030导波检测系统检测了管道中的人工环向切槽和钻孔，给出了数据采集和分析过程及检测数据报告。同时给出了在用管道的现场检测数据分析结果和缺陷验证情况。实验和现场检测表明，磁致伸缩T模态导波技术在管道检测上具有较高的准确性和快捷性。
- 导波检测 /
- 磁致伸缩效应 /
- 管道 /
- 腐蚀
Abstract: The principle of Tmode magnetostrictive guided wave technique for the inspection of defect in pipe was introduced. The artificial defects including circumferential notches and drilled holes were inspected using a magnetostrictive guided wave inspection system MsSR3030. The processes of data acquirement and analysis were given as well as data report of inspection. The practice of the pipe inservice inspection was also introduced. Testing results validated the high accuracy and shortcut of Tmode magnetostrictive guided wave inspection for pipes.
- Guided wave testing /
- Magnetostrictive effect /
- Pipe /
- Corrosion

[1]	蔡国宁.超声导波在液化气管道检测中的应用[J].无损检测,2005,27(3):117-120.
[2]	Kwun H, Bartels K A. Magnetostrictive sensor technology and its applications[J]. Ultrasonics,1998,(36):171-178.
[3]	吴斌,刘增华,王秀彦,等.利用纵向导波检测充水管道周向缺陷的实验研究[J].中国机械工程,2005,16(22):2038-2043.
[4]	何存富,李颖,吴斌,等.空心抽油杆的超声导波检测[J].无损检测,2005,27(10):538-541.
[5]	金建华,申阳春.一种用于管道检测的磁致伸缩式周向超声导波传感器[J].传感技术学报,2004,(4):576-579.
[6]	王悦民,康宜华,武新军.管道超声导波无损检测技术应用研究[J].海军工程大学学报,2005,17(5):34-37.
[7]	何存富,刘增华,吴斌.传感器在管道超声导波检测中的应用[J].传感器技术,2004,23(21):5-8.
[8]	Kwun H, Holt A E. Feasibility of underlagging corrosion detection in steel pipe using the magnetostrictive sensor technique[J]. NDT & E International,1995,28(4):211-214.
