采油树控制阀焊接层的超声检测

详细信息

Ultrasonic Testing of the Welding Layer of the Controlled Valve Used in Subsea Trees

摘要: 研制了检测采油树控制阀焊接层的超声检测系统。系统使用5 MHz超声直探头垂直入射超声波, 液浸法耦合, 采用Bore, Raster和Polar三种检测模式对试样的特定部位进行检测, 4轴编码器给出三种模式的各自坐标位置, 扫描成像结果可以直观显示检测部位的缺陷形貌。对试样的检测结果表明, 该检测方法能够检测出焊接层中大小为 3 mm的垂直圆孔人工缺陷, 对检测类似形状的工件提供了一种可行的检测方法。
- 采油树 /
- 超声C扫描成像 /
- 超声检测
Abstract: The ultrasonic testing system of detecting the welding layer of the controlled valve used in subsea trees was manufactured. The 5 MHz probes were used, producing vertical incident ultrasound, coupled by liquid. Three different detection modes were designed to detect the corresponding specific positions. The coordinates of each location of the three modes were read by the 4-axis encoders. The results of scanning image could visually show the information of defects. The detection results showed that the detection method was able to detect the  3 vertical round holes in the welding layer, which provided a feasible detection method to detect the work piece of the similar shape.
- Subsea trees /
- Ultrasonic C-scan image /
- Ultrasonic testing

[1]	滕永平, 张志永.汽轮机转子中心孔超声成像检测方法研究［C］//第一届国际机械工程学术会议, 上海: 中国机械工程学会, 2000.
[2]	吴迪, 张兆东, 韩秀甫, 等.通用扫描成像检测软件的开发及应用［J］.无损检测, 2003, 25(8): 403-406.
[3]	蒋危平, 田建新, 王子诚.数字化超声波探伤仪十五年技术进展［J］.无损检测, 2004, 26(3): 145-148.
[4]	郭成彬, 蒋危平.认识数字超声探伤仪［J］.无损检测, 2004, 26(3): 149-158.
[5]	王保军, 滕永平, 吴迪, 等.罐壁超声成像测厚系统的设计［J］.无损检测, 2005, 27(8): 402-404.
[6]	李明轩.检测声学应如何面对时代的发展［J］.应用声学, 2006, 25(3): 129-130.
[7]	王科, 滕永平.钻杆接头超声检测方法研究［J］.无损检测, 2007, 29(6): 338-340.
[8]	陈宁宁, 滕永平, 王科.机车车轮在线超声波检测方法研究［J］.无损检测, 2007, 29(7): 402-403.
